High Strength Fiberglass Geogrid
Product Feature
1.High tensile strength:reducing reflective cracking
2.Low elongation, its break elongation is less than 4%
3.Creep resistance
4.Consistency
5.Temperature Stability
6.Nesting,Interlock and Restraint Effects
Product Function
1. It reinforce old asphalt concrete road surface and asphalt layer, and prevents damage;
2. It is used for rebuilding cement concrete road surface into composite road surface and restraining reflection caused by block contraction.
3. It is used in road expansion and improvment project and crack caused by old and new combination position and uneven sedimentation;
4. Coated Fiberglass Geogrid is used in soft soil base reinforcement treatment ,is favorable for soft soil water separation and concretion,restrains sedimentation effectivly,distributes stress uniformly and improve overall strength of road base;
5. High Strength Fiberglass Geogrid is sued for preventing contraction crack caused by new road semi-rigid base layer,and reinforces and prevents road surface crack caused by foundation crack reflection.
Specification
|
Performance/Specification |
GG25-25 |
GG30-30 |
GG40-40 |
GG50-50 |
GG80-80 |
GG100-100 |
GG120-120 |
|
|
Intensity (KN/m) |
Longitudinal |
≥25 |
≥30 |
≥40 |
≥50 |
≥80 |
≥100 |
≥120 |
|
|
Horizontal |
≥25 |
≥30 |
≥40 |
≥50 |
≥80 |
≥100 |
≥120 |
|
Break elongation ratio (%) |
Longitudinal |
≤3 |
≤3 |
≤3 |
≤3 |
≤3 |
≤3 |
≤3 |
|
|
Horizontal |
≤3 |
≤3 |
≤3 |
≤3 |
≤3 |
≤3 |
≤3 |
|
Mesh size (mm×mm) |
12~50 |
12~50 |
12~50 |
12~50 |
12~50 |
12~50 |
12~50 |
|
|
Breadth (m) |
1~6 |
1~6 |
1~6 |
1~6 |
1~6 |
1~6 |
1~6 |
|
Feicheng Lianyi Engineering Plastic Co., Ltd has been a leader market for more than 16 years in manufacturing geosynthetics material for domestic and export markets.
The products we product are Plastic geogrid, biaxial geogrid, high tensile strength geogrid made in China, Polyester Geogrid,Plastic geogrid, biaxial geogrid, high tensile strength geogrid made in China & Polyester Geogrid 50/50KN Stitched with lightweight spunbond nonwoven geotextile, Plastic geogrid, biaxial geogrid, high tensilestrength geogrid made in China & Polyester Geogrid Composite with spunbond nonwoven geotextile, or needlepunched nonwoven geotextile by glue, PP Biaxial Geogrid, HDPE and PP Uniaxial Geogrid, Combigrid ( PP Biaxial Geogrid composite with nonwoven geotextile by welding), HDPE Geomembrane, HDPE Geocell,Mining Geogrid, Geonet, PP Woven Geotextile etc.
If you are interested in the product, contact 2bvideo.com for more information for more information
The information of 2bvideo.com limited shown above is provided by the user or collected on the network. Video 2B does not guarantee the authenticity,accuracy and legitimacy of 2bvideo.com limited information. Video 2B does not involve legal relationships and disputes between users arising from transactions other than secured transactions on this website. Disputes shall be settled by you through negotiation. If you are the person in charge or relevant employee of this enterprise, if you find that the enterprise information is incorrect or want to manage thiscompany, please contact us jacklee1558@gmail.com, after you claim the enterprise, you can obtain management permission, publish supplyand demand information, bring consulting orders, and remove page advertisements.
Main Product:
Geogrid,
Nonwoven Geotextile,
Fiberglass Geogrid ,
HDPE Geomembrane,
Polyester Geogrid,
PP Biaxial Geogrid
