Product details
Usable bandwidth (-10 dB):35 Hz – 20 kHz (K2 70)
Maximum SPL1:147 dB (preset [K2_70])
Nominal directivity (-6 dB):Horizontal : 110° / 70° symmetric ; 90° asymmetric (35°/55° or 55°/33°)
Vertical : depends on the number of elements and array curvature
Foshan Chengze Sound Optoelectronic Technology Co., Ltd. specializes in producing a series of products including linear array speakers, subwoofers, monitoring speakers, and digital amplifiers. We are a manufacturer from China and have been focusing on the sound and light industry for over a decade. We hope to help you meet your needs. Please contact us
LF: 2 × 12″ cone drivers(2 × 8 Ω)
MF: 4 × 6.5″ cone drivers(8 Ω)
HF: 2 × 3″ diaphragm compression drivers(16 Ω)
Acoustical load:
LF: bass-reflex, L-Vents
MF: bass-reflex
HF: DOSC waveguide, Panflex
Connectors:2 x 8-point PA-COM
Rigging and handling:
Captive 4-points rigging system
2 large side handles
Inter-enclosure angles : 0.25, 1, 2, 3, 4, 5, 7.5 or 10°
Cabinet:Premium grade Baltic birch plywood
Side:Die cast aluminium
Rigging components:High grade steel with anti-corrosion coating
Finish:Dark grey brown – Pantone 426 C
IP:IP55
Weight (net):56 kg
Size:354mm×400mm×1342mm
