100mm Steel Cord Tubular Conveyor Belt

Structure and Composition
- The Steel - wire Rope Tubular Conveyor Belt is a specialized type of conveyor belt. It consists of a tubular - shaped body with a core made of steel - wire ropes. These steel - wire ropes are embedded within the belt structure and are the key element providing high tensile strength. The outer part of the belt is usually covered with rubber or other durable materials such as PVC (polyvinyl chloride). The rubber or PVC covering serves multiple purposes, including protecting the internal steel - wire ropes from corrosion, providing abrasion resistance against the conveyed materials, and ensuring a smooth surface for efficient material transportation.
Advantages
- High Tensile Strength: The steel - wire rope core gives the conveyor belt an exceptional ability to withstand heavy loads. This makes it suitable for transporting large - volume and heavy - weight materials over long distances. For example, in mining operations, it can effectively carry tons of ores from the mining site to the processing plant without the risk of belt breakage due to excessive tension.
- Good Sealing Property: When formed into a tubular shape during operation, the belt provides excellent sealing. This is crucial for preventing material spillage and protecting the materials from external contaminants such as dust, rain, or other environmental factors. In the food or pharmaceutical industries, this sealing ability ensures the quality and purity of the conveyed products.
- Flexibility and Adaptability: Despite its high strength, the belt also shows good flexibility. It can smoothly pass through various conveyor components such as pulleys and idlers. The tubular shape can be easily adjusted to fit different conveyor configurations and can even make turns in a three - dimensional space, allowing for more flexible material transportation routing in complex industrial settings.

Technical parameters：

Diameter（mm）	100	150	200	250	300	350	400	500	600	700	850
Midth(mm)	400	600	780	1000	1150	1300	1530	1900	2250	2650	3150
Section Squre 100%	0.0079	0.018	0.031	0.053	0.064	0.09	0.147	0.21	0.291	0.3789	0.5442
Section Squre 75%	0.0059	0.013	0.023	0.04	0.048	0.068	0.11	0.157	0.218	0.2842	0.4081
Largest Size	30	30-50	50-70	70-90	90-100	100-120	120-150	150-200	200-250	250-300	300-400
The width of Conventional Belt conveyor		300-400	500-600	600-750	750-900	900-1050	1050-1200	1200-1500	1500-1800	1800-2000	2000-2400
