Tanker truck

Tanker truck

7 month ago

8 0

Hubei Ocean Automobile Industry Co., Ltd.

 8 month year

Product details

Chassis configuration: Aoling 3800 wheelbase, engine model D30TCIF1, Fast 8 gear, 2060 cab, ordinary seat,

multifunctional steering wheel, car networking terminal,MP3, speed limit device, constant speed cruise,

Beidou dual-mode vehicle terminal + driving recorder, ABS, central lock + electric door and window lifting + remote control,

manual air conditioning, front axle 3.6T rear axle 6T, speed ratio:4.33, tire 9R22.5, front disc rear drum, dead brake,

with power take-off, double warning.

Top configuration: Volume 8.4 cubic meters, tank adopts Q235 high-quality carbon steel plate,

circular gear oil pump (can be pumped in and out), single bin (can be customized for multiple bins),

complete set of bottom loading oil system (including 1 bottom loading oil discharge valve,

1 oil and gas recovery valve, 1 oil and gas recovery interface, 1 set of pneumatic combination switch,

1 anti-overflow probe rod and 1 socket), 1 European standard tank cover, 1 submarine valve,

folding lifting guard on both sides of the top of the tank, anti-skid steel net on the top,

3M orange reflective belt and reflective strip on both sides of the tank, three" flammable liquid" signs,

safety notice board, dangerous brand, dangerous goods triangle lamp, one tool box, two oil pipes,

two fire extinguishers, and others are manufactured according to standard configuration.

Optional installation of large flow refueling machine, 15 meters automatic return reel and refueling gun.

All main welds of the tank body shall be operated in strict accordance with the flaw detection process (single-side welding,

double-side forming: panel welding-copper groove, circumferential seam welding-ceramic gasket process),

and flaw detection (x-ray inspection) shall be carried out according to the flaw detection proportion specified in GB18564.1-2019

standard.Sand blasting process The surface of the tank is sandblasted to achieve the effects of ash removal,

stain removal and rust removal, and enhance the thickness and adhesion of the paint.

The paint baking process realizes pre-installation + paint baking + final assembly,

and the entire vehicle has no dead spots or omissions in the paint.
