Identification | Product model | XR15 | XR20 | ||||||
Power supply | Electric | ||||||||
Operating type | Standing | ||||||||
Load capacity | Q Kg | 1500 | 2000 | ||||||
Load center distance | C mm | 500 | |||||||
Load distance | X mm | 446 | 646 | ||||||
Wheelbase | Y mm | 1390 | 1590 | ||||||
Weight | Weight (without battery) | Kg | 1700 | 1780 | |||||
Axle loading, loaded drive end / load end |
Kg | 1338/2112 | 1520/2230 | ||||||
Axle loading, unloaded drive end / load end |
Kg | 1372/578 | 1542/612 | ||||||
Wheel | Tyres | Polyurethane | |||||||
Tyre size drive end | mm | Φ230x75 | |||||||
Type size load end | mm | Φ210x85 | |||||||
Balancing wheel size | mm | Φ125x60 | |||||||
Wheels number (x=drive wheel) drive end/load end | 1x-2/2 | ||||||||
Tread width drive end | mm | 740 | |||||||
Tread width load end | mm | 985 | |||||||
Dimensions | Height data is on the bottom - Height data choices | ||||||||
Forks height,lowered | h5 mm | 35 | |||||||
Height of handle in drive position (Max/Min) | h6 mm | 1380/1020 | |||||||
Overall length | L1 mm | 2090 | 2290 | ||||||
Length to face of forks | L2 mm | 1185 | |||||||
Overall width | b1 mm | 1090 | |||||||
Fork dimensions (Forging) | s/e/l mm | 100/35/1070 | |||||||
Forks width | b3 mm | 200-720 | |||||||
Reach length | L3 mm | 580 | |||||||
Minimum ground clearance | m mm | 55 | |||||||
Aisle width for pallets 1000x1200 lengthways | Ast mm | 2410 | 2610 | ||||||
Aisle width for pallets 800x1200 lengthways | Ast mm | 2610 | 2810 | ||||||
Turning radius | Wa mm | 1656 | 1756 | ||||||
Inside width between the guides | b4 mm | 780 | |||||||
Performance | Travel speed loaded/unloaded | km/h | 4.8/5.6 | ||||||
Lift speed loaded/unloaded | mm/s | 90/120 | |||||||
Lowering speed loaded/unloaded | mm/s | 125/80 | |||||||
Max gradeability loaded/unloaded | % | 5/8 | |||||||
Service brake | Electromagnetic | ||||||||
Electric Motor | Drive motor rating | kW | 1.2(DC),1.5(AC) | ||||||
Lift motor rating | kW | 2.2/3.0 | |||||||
Battery voltage / nominal capacity | V/Ah | 24/240-280 | |||||||
Battery weight | Kg | 250(280) | |||||||
Others | Type of drive control | MOSFET Control | |||||||
Noise level at operator's ear | dB(A) | <70 | |||||||
Height Data Choices | |||||||||
Mast type | Lift | Height with mast closed | Free Lift | Height with mast Extended | |||||
h3 (mm) | h1 (mm) | h2 (mm) | h4 (mm) | ||||||
Single | 1600 | 2030 | 1000 | 2540 | |||||
Dual | 2500 | 1780 | 90 | 3440 | |||||
Dual | 3000 | 2030 | 90 | 3940 | |||||
Dual | 3500 | 2280 | 90 | 4440 | |||||
Dual | 4000 | 2590 | 90 | 4940 | |||||
Triple | 4500 | 2060 | 1500 | 5340 | |||||
Triple | 4800 | 2160 | 1600 | 5640 | |||||
Triple | 5000 | 2230 | 1660 | 5840 | |||||
Triple | 5500 | 2400 | 1820 | 6340 |
