DMX 3D Club Lighting LED Tubes
Standard DMX512 protocol 3D LED Tube Light, SMD5050 RGB Leds, Clear PC tube, Black PCB board. DMX 3D club tubes are mature products, widely used in club led lighing
One meter is 16pixel,48CH DMX address. One meter both sides 64pcs supper bright Epistar SMD RGB LED (one side) make it 360 viewing.
1. Size: 0.5m, 1m,1.5m, 2m length
2. Clear PC cover giving 360 degree viewing
3. Standard DMX 512 control, 44frames/second, manual customized
4. 3D pixel mapping to set on the software programming
5. Protections: short circuit, over current, over temperature
6. With working life-span at least 50,000hrs
7. IP65 waterproof with good design of the housing
Products Description of DMX 3D LED Tube Light
|
Model NO. |
LED-3DT30DMX3208 |
LED-3DT30DMX6416 |
LED-3DT30DMX9624 |
LED-3DT30DMX12832 |
|
Diameter |
30mm |
30mm |
30mm |
30mm |
|
Length |
500mm |
1000mm |
1500mm |
2000mm |
|
Color |
■■■ SMD RGB 5050 |
|||
|
LED QTY |
32LEDs |
64LEDs |
96LEDs |
128LEDs |
|
Pixel QTY |
8 Pixels |
16 Pixels |
24 Pixels |
32 Pixels |
|
Tube Qty/Universe |
20 Tubes |
10 Tubes |
7 Tubes |
5 Tubes |
|
Operating Voltage |
DC15V |
DC15V |
DC15V |
DC15V |
|
Max Power |
MAX=8W |
MAX=16W |
MAX=24W |
MAX=32W |
|
Control Protocol |
DMX512 |
DMX512 |
DMX512 |
DMX512 |
|
Address Setting |
Manually |
|||
|
LED Source Life |
50,000hours,based on LED manufacturers` test data |
|||
|
Housing |
Clear cover |
|||
|
Temperature |
-4℉ to 122℉(-20℃ to 50℃) operating temperature |
|||
|
Humidity Range |
0 to 95% non-condensing |
|||
|
Protection |
IP65 |
|||
|
Net Weight |
180g |
350g |
500g |
670g |
|
Note |
1, diameter 15mm, 30mm, 50mm , 3D LED Vertical tube is available 2, Comparing with DMX512 protocol , if you need economic solution, we recommend SPI protocol |
|||
Photo Show for DMX 3D LED Tube Light:
Related controller:
Packing and shipping of DMX 3D LED Tube Light :
Standard carton
50pcs tubes in one carton
Package Size 113*38*24cm
Delivery Details : 7-12 working days
DHL,Fedex,UPS,TNT available . you can also use your own logistics.
DHL express is about 3-5days working day for delivery.
