Winson Z11-611 OEM Embedded 2D Barcode Module mini auto-scanning module
Barcode EngineSanner module Can scan the phone, computer and other electronic screen.
Super Handheld Computer Super scanning and decoding ability, can read incomplete and fuzzy codes.
|
Technical parameter |
|
|
Electrical Characteristics |
|
|
Interface |
USB/ RS-232/TTL |
|
Voltage requirement |
DC 5V±5%(USB,RS232,RS485) DC 3.3V±5%(TTL-232) |
|
Current consumption |
Max:135mA,Min:74mA |
|
Optical Characteristics |
|
|
photo sensor |
CMOS array sensor |
|
SENSOR RESOLUTION |
1280X800 pixels |
|
light source |
8 White LED |
|
Performance Characteristics |
|
|
Decode angle |
Pitch angle:±65°;Skew angle:±40°;Tilt angle:±180° |
|
Min.PCS value |
>20%UPC/EAN 13(13mil) |
|
Field of View |
54°(H),33°(V) |
|
Language |
multiple languages |
|
Identification |
1D : UPC-A/UPC-E;EAN-8/EAN-13;Code128;Code39;Code93;Code32; Code11;Codabar;Plessey;MSI;Interleaved 2 of 5;IATA 2 of 5;Matrix 2 of 5; Straight 2 of 5;Pharmacode;RSS-14;RSS-14 Expanded;RSS-14 Limited; Composite Code-A;Composite Code-B;Composite Code-C; |
|
2D:PDF417;Micro PDF417;Data Matrix;QRcode;Micro QR;Aztec; MaxiCode |
|
|
Physical Characteristics |
|
|
Dimensions |
78mm*67mm*54mm |
|
Weight |
180g |
|
Shock drop test |
1.2m drop onto concrete surface |
|
Environmental Characteristics |
|
|
Operating temperature |
-10°C to 60°C |
|
Storage temperature |
-10°C to 70°C |
|
Humidity |
5 - 90% (No condensation) |
If you are interested in the product, contact 2bvideo.com for more information for more information
