CHARACTERISTICS
It is suitable for ultra-fine crushing of dry and brittle materials, and it is easy to obtain materials of several microns
● Because mainly by the powder between the grinding, the product is not easy to pollution, high purity;
● No running parts, in addition to the normal wear of the lining, other parts generally will not be damaged;
● Airtight dust free, environmental protection;
Low noise, no vibration, convenient disassembly and cleaning;
● Can achieve large capacity continuous production, high degree of automation:
● According to different properties of materials, select the corresponding lining materials (mainly around the crushing chamber and the part of the inlet and outlet pipes) to solve the hard materials (Moh hardness is not more than 9) and wall adhesive materials in the crushing caused by the problem.
WORKING PRINCIPLE
The raw material is input from the hopper, sprayed into the crushing cavity, and the supersonic air flow ejected from the crushing nozzle forms a logistics, colliding with each other, friction and obtain the micro powder, the micro powder is imported into the center outlet, collected with the air discharge, the coarse powder is thrown to the crushing area due to centrifugal force to continue to crush.
INFORMATION DETAILS
The crushing chamber of flat air jet mill has simple structure and low maintenance rate, so it is widely used. Structure: It is mainly composed of crushing chamber, nozzle mouth, discharge port air flow outlet, compressed air inlet, grading area, etc
APPLICATION
● Non-metallic ore powder processing: kaolin, talc powder, graphite, light calcium carbonate, mica, vermiculite, spinel, attachorite, wollastonite, brucite, bentonite, etc.
● Chemical powder processing: aluminum hydroxide, silica gel, white carbon black, wood powder, epoxy resin, toner, foaming agent, magnesium hydroxide, cellulose, molybdenum trisulfide, antimony trioxide, titanium dioxide, alumina, dyes, pigments, etc
● Pesticide powder processing: carbendazim, methyl tobuzin, herbicide powder, insecticide powder, fungicide powder wettable powder, etc
● Pharmaceutical powder processing: green tea, salvianthus miltiorrhiza, pearl powder, terrapin powder, panax notoginseng, west green fruit, nimodipine, fenofiate, ibuprofen, bismuth nitrate, cortisone, penicillin, pollen, pearl powder, nimodipine equal
● Pigment powder processing: iron oxide, chromium oxide, phthalocyanine, cadmium red, cadmium blue, etc
● Battery material powder processing: lithium cobaltate, cobalt oxide, lithium manganate, manganese dioxide, lithium nickel cobaltate, lithium carbonate, coke, graphite, lithium iron phosphate, asphalt, composite materials, etc
● Flame-retardant material powder processing: magnesium oxide, magnesium carbonate, zinc oxide, zinc borate, magnesium hydroxide, etc.
Our ain products are air jet mill, horizontal jet mill , vertical jet mill , lab jet mill, plat or spiral jet mill, air classifier, single or multiple rotor air classifier, handstand air classifier, lab air classifier, ball grinding mill classifier, CJ series ultrafine jet mill, CJ traditional chinese medicine ultrafine jet mill, dry desulfurization equipment,professional equipment for deep processing of cracking carbon black,lithium cathode material crusher equipment,lithium cathode material crushing classification professional equipment and so on.
Type
QLMB-1.7
QLMB-3
QLMB-6
QLMB-10
QLMB-15
QLMB-20
QLMB-30
QLMB-40
Air pressure(Kgf/cm2)
6.5-12
Air consumption(m3/min)
1.7
3.0
6.0
10.0
15.0
20.0
30.0
41.4
power
11
37
45
79
90
132
210
270
Handling capacity
0.5-20
2.0-50
10-100
20-200
50-300
100-500
300-800
600-1200
If you are interested in the product, contact 2bvideo.com for more information for more information
