Product details

Once 300-1400MM Concrete Pile Mold was launched, it was well received by users and the market feedback was excellent, which really solved the pain points of users.A concrete pile mould is a type of mould used in the manufacturing of concrete spun piles. These pile steel moulds are used in construction projects to provide support and stability to structures such as bridges, buildings, and other large structures. The pile mould is typically made of steel and is designed to create a cylindrical shape with a smooth surface finish. The mould is used to form the concrete around a central steel reinforcement cage, which is then spun at high speeds to compact the concrete and remove any air pockets. This process creates a strong and durable pile that can withstand heavy loads and harsh environmental conditions. The use of concrete spun piles has become increasingly popular in recent years due to their cost-effectiveness, durability, and ease of installation.

300-1400MM Concrete Spun Pile Column Mould

Inside Ddameter of small end (mm)	Wheelbase(mm)	Wheel Diameter(mm)	Length(m)
300	2000	510	7-11
350	2000	610	7-11
400	2000	610	7-12
450	2000	710	7-12
500	2000	710	7-12
550	2000	810	7-12
600	2000	810	7-15
800	2000	1010	7-15
1000	2000	1210	7-15

Concrete Spun Pile Column Mould is used for concrete pole making. Its mainly manufacture technology is longitudinal tension by steel wires. Then it can squeeze out the excess water in the concrete under the centrifugal force. Thus, it can greatly improve the concrete density and strength.

In order to form concrete more quickly to meet the design strength of more than 70%, steam curing can be carried out so as to shorten the mould-releasing cycle

300-1400MM Concrete Spun Pile Column Mould

1. Saving a great deal of steel, about 30~70% (employing cold drawn steel wire can save 30%~60%; employing high stress steel wire can save 40%~69%).

2. Crack resistance can increase about 3~5 times.

3. Rigidity increases 1~3 times.

4. Reducing the cost (using cold drawn steel wire can reduce 25%~40%; using high stress steel wire can reduce 12%~21%).

5. Good durability, can delay the existence and expansion of cracks.

6. Protect the environment on which human beings depend on for existence, and reduce the deforestation.
