Product details

Copper-Nickel Alloy tube:
1)Up to GB/T8890/ASTM B111/JIS H3300/BS EN12451 standards and so on.
2)Material designation: BFe10-1-1 / C70600 / C7060X / CuNi10Fe1Mn / CuNi9010 / Cu90Ni10 and BFe30-1-1 / C71500 / CuNi30Mn1Fe / CuNi7030 / Cu70Ni30 or other alloy
Material Brand of Copper-Nickel Alloy tube:

Grade	USA	U.K	Germany	Japan
China BG	ASTM	BS	DIN	JIS H
BFe10-1-1	C70600	CN102	CuNi10Fe1Mn	C7060
BFe30-1-1	C71500	CN107	CuNi30Mn1Fe	C7150

3)Tubes temper: All tempers are available (Goods supply state: Annealed condition)
4)Dimensions: Outer diameter:5-419mm, Wall thickness: 0.5-10mm or according to the buyers' requirements, and also length and tolerance subject to the buyer's decisions.
5) Tubes in good straightness, with clean surface of both inside and outside
6)Application range: Copper-Nickel Alloy tube for condenser and heat-exchangers, Water Evaporators, Boiler Blowdown Heat Exchangers, air coolers, Gland Steam Condensers, Steam Ejector, Turbine Oil Coolers, Fuel Oil Heaters, Compressed Air Inter and After Coolers, Ferrules, Oil Well Pump Liner, Distiller , Marine Industry , and Nuclear Power etc.
C70600 Copper Nickel "90/10"ASTM B151, MIL C15726F, SAE J461, SAE J463C70600 (C706) & C71500 (C715), Copper nickel offers excellent corrosion resistance, especially in marine salt water environments. The main, wrought copper-nickel alloys chosen for sea water service contain 10 or 30 percent nickel. They also have important additions of iron and manganese which are necessary to maintain good corrosion resistance.Typical Uses for C706 Copper Nickel "90/10":AUTOMOTIVE: Power Steering Tube, Brake Lines
CONSUMER: Screw Lamp Bases
INDUSTRIAL: Condenser Plates, Condensers, Weld Torch Tips, Heat Exchanger Tubes, Valve Bodies, Evaporator Tubes, Pressure Vessels, Distiller Tubes, Pump Impellers for Oil Refining, Ferrules, Evaporators
MARINE: Boat Hulls, Tube Sheet for Salt Water Service, Salt Water Pipe Fittings, Salt Water Piping Systems, Salt Water Piling Wrap, Hot Water Tanks, Salt Water Baffles, Propeller Sleeves, Ship Hulls, Water Hoses
PLUMBING: FlangesSizes Available From Hehong Precision(New Huahong Copper)TUBE&PIPE: 1/4" - 16" diameter , 6.35mm - 419mm diameter for seamless.
Bar:8-90,100,168mm diameter.
Copper-nickel UNS C70600 has a copper content of not less than 88.6%.
Tabulated below are the mechanical properties of UNS C70600 tubes as a function of heat treatment.

Temper	Tensile Str.	Yield Str.	Elong.	Rockwell
Temper	Tensile Str.	Yield Str.	Elong.	B	C	F	30T
H55	414MPa (60ksi)	393MPa (57ksi)	10%	72	-	100	70
OS025	303MPa (44ksi)	110MPa (16ksi)	42%	15	-	65	26

The chemical composition of UNS C70600 copper alloy is outlined in the following table.

Elements	Content (%)
Nickel, Ni	9.0-11.0
Iron, Fe	1.0-1.8
Zinc, Zn	1.0
Manganese, Mn	1.0
Lead, Pb	0.05
Copper, Cu	Remainder

Equivalent materials to UNS C70600 copper alloy are given in the table below.

ASME SB111	ASME SB171	ASME SB359	ASME SB466	ASME SB467
ASME SB395	ASME SB543	ASTM B111	ASTM B151	ASTM B122
ASTM B171	ASTM B359	ASTM B395	ASTM B432	ASTM B466
ASTM B469	ASTM B543	ASTM B608	DIN 2.0872	MIL C-15726
MIL T-15005	MIL T-16420	MIL T-22214	SAE J461	SAE J463
