2.05P various pitch row of pin connectors
Pin connector is an indispensable part of electronic equipment, it is blocked in the circuit or isolated between the circuit, bridging the communication, so that the current flow, so that the circuit to achieve the intended function. Connector row pin form and structure is ever-changing, with the application object, frequency, power, application environment, etc., there are different forms of connectors. Despite the many types of connectors, but the basic performance can be divided into three categories: mechanical performance, electrical performance and environmental performance.
In terms of the function of the row of pin-type connectors, plugging force is an important mechanical properties. Insertion force is divided into insertion force and pull-out force (pull-out force is also known as separation force), the requirements of the two are different. In the relevant standards have a maximum insertion force and minimum separation force provisions, which indicates that, from the point of view of use, the insertion force to be small (so that there is a low insertion force LIF and no insertion force ZIF structure), while the separation force if too small, it will affect the reliability of the contact.
Another important mechanical property is the mechanical life of the connector. Mechanical life is actually an indicator of durability, in the national standard GB5095 to call it mechanical operation. It is inserted once and pulled out as a cycle, in the specified plugging and unplugging cycle after the connector row of pins can normally complete its connection function (such as contact resistance value) as the basis for judging. Connector insertion and removal force and mechanical life of the contact structure (positive pressure size) contact parts of the quality of the coating (coefficient of sliding friction) and the size of the contact arrangement accuracy (alignment).
[Product name] : Pin connector / female connector / female connector / female connector / female connector
[Pitch] :1.0/1.27/2.0/2.54
[Material] :PBT/PA6T/PA9T/PPS
[Style] : Single row/Double row/Three row/four row/In-line /90 degree /SMT
[Color]: Black and white
[Explanation] : Free sample, according to customer requirements arbitrary customization
Connectors are an indispensable part of electronic equipment. Our main products are: Round connector, square pin row female connector, board to board connector, board to board connector, board to wire connector, New energy connector, round hole pin row connector, female connector, Cabinet Light connector, four policy pin row connector, female connector, Jane Ox connector, Ox horn connector, wire to board connector, top connector, flat cable, DuPont flat cable, wiring harness, IDC socket
If you are interested in the product, contact 2bvideo.com for more information for more information
