Glazed tile Cold Roll Forming Production Line
Introduction of glazed tile cold roll forming production line
This production line can complete the forming of glazed roof tile. Other similar cold-formed steels can also be produced by replacing rolls and related tools and dies.
Technical Parameters of 0.6x1500 glazed roof tile cold roll forming production line:
Material： Galvanized sheet
Yield strength of raw materials： ≤235Mpa
Tensile strength of raw materials： ≤550Mpa
Outer Diameters of Coils： ≤Ф1300 mm
Inner Diameter of Coils： Ф508
Steel strap width： ≤1500mm
Steel Strap Thickness： 0.3~0.6mm
Weight/Coil： ≤10000 kg
Allowable coil inner diameter: Ф508
Maximum allowable roll diameter: Ф1300mm
Maximum allowable roll width: 1500 mm
Maximum roll carrying weight: ≤10000 kg
Forming passes: 22 passes (subject to the final design)
Shaft diameter of forming machine: φ90
Motor power: 7.5kwX2
Maximum linear speed: 2~5m/min
Advantages:
The color steel plate glazed tile produced by the color steel tile equipment is a new type of building material. The color steel plate is used as the base plate and processed by cold bending, pressing, cutting and other processes. The color is rich, classical and elegant, and the product is light in weight, high in strength, and waterproof. It has good performance, easy and fast installation, and can be widely used in villa roofs, urban flat slopes, and tourist attractions.
The forming unit adopts motor, reducer and chain drive.The arch of the molding machine is an independent arch structure (non-plate structure), with stable performance, reliability and high precision.
The lower shaft is driven, and the upper and lower shafts use synchronous gears when necessary.
The base is a steel welded structure. Annealing after welding.
The forming roll is designed by professional software, and the material is high-quality 45 steel, plated with hard chrome.
Picture Show:
