Bona new type PVC fitting injection molding machine are specialized for different sizes of PVC fitting. Saving 30%~50% of energy by using servo motor and more device options are available to fulfill customer requirements.
Specialized PVC Process – Standard TECHMATION control system, the control procedure is special designed for PVC fitting.
Widened Door – Widened safe door makes easier for removal of PVC fitting .
PVC Screw – Specialized PVC Screw solve the problems of drawing and yellowing of PVC products effectively.
Air Cooling – Excellent air cooling control improve the stability of PVC heat-sensitivity molding process.
Plasticization Precision – The charge adopts high torque and low speed motor, which improves the plasticization precision.
Servo & Variable Drives – Servo and Variable pump are available according to every production conditions.
Core Pulling – Standard two sets of core pulling, more sets of core pulling are available.
Temperature Control – Solid state replays for temperature control is used to ensure that the barrel temperature is controlled within a reasonable range.
| NINGBO BONA MACHINERY CO.,LTD. | |||||
| SPECIFICATION |
|
|
|
|
|
| ITEM |
|
UNIT | BN388II | ||
| Injection Unit | Screw Diameter | mm |
|
80 |
|
| Screw L/D Ratio | L/D |
|
20.7 |
|
|
| Injection Volume | cm3 |
|
1648 |
|
|
| Shot Weight | g |
|
1500 |
|
|
| Injection Pressure | Mpa |
|
150 |
|
|
| Clamping Unit | Clamping Force | KN | 3880KN | ||
| Opening Stroke | mm | 700 | |||
| Mould Thickness(Min-Max) | mm | 730-730 | |||
| Space Between Tie-Bars | mm | 280X730 | |||
| Ejector Force | KN | 102 | |||
| Ejector Stroke | mm | 200 | |||
| General | Motor Power | KW | 55 | ||
| Heater | KW | 24.5 | |||
| Pump Pressure | Mpa | 17.5 | |||
| Machine Dimension | m | 7.3X1.85X2.5 | |||
| Machine Weight | T | 14 | |||
| Mould Orientation Ring Diameter | mm | Φ160 | |||
| Nozzle Radius | mm | SR14 | |||
If you are interested in the product, contact 2bvideo.com for more information for more information
