Portable Wireless Ultrasound is a mini ultrasound scanner without screen. probe device combined with integrated ultrasound boards,ultrasound probe integrated with usg board,imaging transmission done by special wifi to pad and phone.We have Single Head Ultrasound Series and Double Head Ultrasound.
Through professional ultrasound software APP,wireless probe wifi connected with smart phone or tablet to become a ultrasound scanner.
Single Head Ultrasound Series have different Specification to chose, including B/W Ultrasound Scanner (80E, 128E, 192E) and Color Doppler Ultrasound (80E, 128E, 192E).
Double Head Ultrasound is Color Doppler Ultrasound with difference probe head to chose, also with different element (128E,192E).
How it works
The Sonostar wireless probe is a mini ultrasound scanner without a screen. We minimize the components of a traditional ultrasound into a small circuit board built into the probe, and showing image in smart phone/tablet through Wifi transferring. image can both show in screen and tablet.Image transferring through internal wifi from probe, no need external Wifi signal.
Feature
-Small and Compact size, easy to carry.
-Wireless type without probe cable, working freely.
-Waterproof design, convenient for sterilization.
-Remote diagnosis convenience, capable for images transfer to doctors.
1-71-61-8
Specification
-Probe Type: Consist by two of Convex, Microconvex, Linear, Small Linear, Transvaginal
-Scanning mode: Electronic array
-Display mode: B, B/M, color doppler version with B+Color, B+PDI, B+PW
-Probe element: 128/192
-Channel of RF circuit board: 32/64
-Probe frequency and scan depth, head radius/width, scan angle(convex):
Convex head 3.5MHz/5MHz, 90/160/220/305mm, 60mm, 60°
Convex head with phased array(cardiac) scan mode: 3.5MHz/5MHz, 90/160/220/305mm, 40mm, 90°
Linear head 7.5MHz/10MHz, 20/40/60/100mm, 40mm
Small Linear head 10MHz/14MHz, 20/30/40/55mm, 25mm
Microconvex head 3.5MHz/5MHz, 90/130/160/200mm, 20mm, 88°
Transvaginal head 6.5MHz/8MHz, 40/60/80/100mm, 13mm, 149°
-Image Adjust: BGain, TGC, DYN, Focus, Depth, Harmonic, Denoise, Color Gain, Steer, PRF
-Cineplay: auto and manual, frames can set as 100/200/500/1000
-Puncture assist function: the function of in-plane puncture guide line, out-of-plane puncture guide line, automatic blood vessel measurement.
-Measure: Length, Area, Angle, heart rate, Obstetrics
-Image save: jpg, avi and DICOM format
-Image frame rate: 18 frames/second
-Battery working time: 2.5 hours(according to whether keep scan)
-Battery charge: by USB charge or wireless charge, take 2 hours
-Dimension: L156×W60×H20mm(if with transvaginal head length is 270mm)
-Weight: 250g
-Wifi type: 802.11g/20MHz/5G/450Mbps
-Working system: Apple iOS and Android, Windows
Product Configuration
Standard Configuration:Wireless Ultrasound Scanner x 1 unit, USB Charging Cable x 1pc,Carrying Bag or Aluminium Suitcase(options) x 1pc.
Optional:Stainless Steel Puncture Guide, Android or iOS Phone/Tablet, Windows PC, Wireless Power Bank, Tablet Bracket, Trolley
Our Services
1. We offer 18 months warranty period, 24 hours calling service.
2. There is OEM&ODM service for distributor.
3. Support iOS, Android, Windows connection, APP belongs to Sonostar, free for lifetime use.
4. 100% Calibration before Shipment.
5. All products will be shipped within 1-3 working days upon payment.
6. After-service: Support return or replacement.
