Flexible 1/2 inch high-pressure rubber air hose is a type of air hose that is commonly used in industrial and construction applications. The hose is designed to withstand high-pressure air applications and is constructed with a synthetic rubber inner tube that provides resistance to oil and abrasion. The hose is reinforced with multiple layers of high-tensile synthetic fibers, which provide strength and flexibility while also maintaining the hose's ability to handle pressure. The outer cover of the hose is typically made of a synthetic rubber material, which provides resistance to weather, ozone, and abrasion. Flexible 1/2 inch high-pressure rubber air hoses are available in a variety of sizes and pressure ratings, with maximum working pressures ranging from 300 psi to 1000 psi. They are commonly used in applications such as pneumatic tools, air compressors, and other high-pressure air systems.
Construction: Tube: NR & SBR synthetic rubber.
Reinforcement: High tensile polyester fiber braided.
Cover: EPDM & SBR synthetic rubber.
Temperature: -30℃ - +70℃
Color: Black, Red, Yellow, Blue, Green, Orange, etc.
Application: Mainly used for conveying of air and water in mining, construction, engineering, shipbuilding, steel
production etc.
Standard length: 50m, 100m.
Specification:
|
Item code |
Inner Diameter |
Outer Diameter |
Working Pressure |
Burst Pressure |
Length |
Measurement |
Weight |
|||
|
inch |
mm |
mm |
bar |
psi |
bar |
psi |
m |
cbm/roll |
kg/m |
|
|
PRA-05 |
3/16" |
5 |
11.5 |
20 |
300 |
60 |
900 |
100 |
0.02 |
0.15 |
|
PRA-06 |
1/4" |
6 |
13 |
20 |
300 |
60 |
900 |
100 |
0.025 |
0.17 |
|
PRA-08 |
5/16" |
8 |
15 |
20 |
300 |
60 |
900 |
100 |
0.03 |
0.22 |
|
PRA-10 |
3/8" |
10 |
17 |
20 |
300 |
60 |
900 |
100 |
0.04 |
0.26 |
|
PRA-13 |
1/2" |
13 |
21 |
20 |
300 |
60 |
900 |
100 |
0.07 |
0.4 |
|
PRA-16 |
5/8" |
16 |
24 |
20 |
300 |
60 |
900 |
50 |
0.06 |
0.45 |
|
PRA-19 |
3/4" |
19 |
29 |
20 |
300 |
60 |
900 |
50 |
0.07 |
0.7 |
|
PRA-25 |
1" (1b) |
25 |
36 |
12 |
180 |
36 |
540 |
50 |
0.09 |
0.85 |
Other Rubber Air Hose Surface: Cloth-Wrapped Surface, Groove Surface.
