High Current Big Power Metal Push Button Switch
This model Metal Push Button Switches is also UL certified, offering a rating of 3A 250VAC. Yeswitch Metal Push Button Switch comply with IP67 standard, ENEC, ROHS, IK08. Furthermore, this Waterpro of Push Button Switch has a long operating life up to 1,000,000 life cycles (momentary) and 500,000 (latching). We also offer multiple color ring illumination options and multiple voltage options for this Anti Vandal Switches. This 25MM Metal Switches comes with a 25mm panel cutout size and SPDT or DPDT function, the DT two-circuit could ensure the line work could runs in order.
This mechanical life of this Illuminated Push Button Switch could reach 1,000,000 cycles and Self-lock is up to 500,000cycles. The ingress degree of this modal Push Button Switches IP67,IK10(Stainless). The applications of this Push On Push Off Switch comprising Industrial control instruments, Medical equipment, Security monitoring equipment, Vehicle peripherals, Audio-visual equipment and Energy storage equipment.
SPECIFICATIONS:
RATING: Ith 5A/250VDC resistive load 3A/250VAC
CONTACT RESISTANCE: 50 mΩmax. @1A 12 VDC(initial value)
INSULATION RESISTANCE: 1,000 mΩmax. @500VDC
OPERETION TEMPERATURE: -20°to 55°
MECHANICAL LIFE: Momentary 1,000,000 cycles
Self-lock 500,000cycles
ELECTRICAL LIFE: 50,000 make-and-break cycles at full load
INGRESS PROTECTION: IP67,IK08(Stainless)
Our Advantages
From the purchase of raw materials to the finished product, all production process (product development/plating/mold and equipment processing/ metalpressing/ plasticinjection/semi-automatic and fully automated equipment assembly, etc.) are completed in the factory. Our metal pressing and plastic injection own the advantages of 100% self-made mold, from a single form to the various forms of application. And we continuously keep innovation and enhance the technology in order to collaborate with our customers to design the most sophisticated products. Yeswitch Electronics Co., Ltd., whether in production base or in quality assurance department in the head office, have professional equipment and technical personnel. In addition to the annual new product development, product improvement and testing are performed as annual plan to ensure that listed products maintain in best quality. Therefore, our long-term customers/partners, get the best quality of the switches.
