An angle joint plate, also known as an angle iron, is a long strip of steel that is perpendicular to each other and forms an angle shape on both sides. There are equal leg angle steels and unequal leg angle steels. The two sides of an equilateral angle steel have equal widths. Its specification is based on the side width × Edge width × The thickness of the side is expressed in millimeters.
What is the composition of Stainless Steel Angle?
Stainless Steel Angle is composed of a combination of iron and at least 10.5% chromium, which gives it the properties of stainless steel such as corrosion resistance and durability.
What are the common applications of Stainless Steel Angle?
SS Angle is commonly used in the construction industry, as well as in the manufacture of products such as brackets, bracing, and frames. Its corrosion resistance makes it ideal for use in marine and food processing environments.
What is the temperature range of stainless steel angles?
Stainless Steel Angles can withstand temperatures up to 1500F (816C) in intermittent service and 1650F (899C) in continuous service.
|
Size in Inches |
Est. Weight per Ft. Lbs. |
Est. Weight per 20' Bar |
|
3/4 x 3/4 x 1/8 |
0.59 |
11.80 |
|
1 x 1 x 1/8 |
0.80 |
16.00 |
|
1 x 1 x 3/16 |
1.16 |
23.20 |
|
1 x 1 x 1/4 |
1.49 |
29.80 |
|
1-1/4 x 1-1/4 x 1/8 |
1.01 |
20.20 |
|
1-1/4 x 1-1/4 x 3/16 |
1.48 |
29.60 |
|
1-1/4 x 1-1/4 x 1/4 |
1.92 |
38.40 |
|
1-1/2 x 1-1/2 x 1/8 |
1.23 |
24.60 |
|
1-1/2 x 1-1/2 x 3/16 |
1.80 |
36.00 |
|
1-1/2 x 1-1/2 x 1/4 |
2.34 |
46.80 |
|
2 x 2 x 1/8 |
1.65 |
33.00 |
|
2 x 2 x 3/16 |
2.44 |
48.80 |
|
2 x 2 x 1/4 |
3.19 |
63.80 |
|
2 x 2 x 3/8 |
4.70 |
94.00 |
|
2-1/2 x 2-1/2 x 3/16 |
3.07 |
61.40 |
|
2-1/2 x 2-1/2 x 1/4 |
4.10 |
82.00 |
|
3 x 3 x 1/4 |
4.90 |
98.00 |
|
4 x 4 x 1/4 |
6.60 |
132.00 |
|
4 x 4 x 3/8 |
9.80 |
196.00 |
If you are interested in the product, contact 2bvideo.com for more information for more information
