Forged 4340 Steel Connecting Rod For Honda Acura K24 K24A Connecting Rod

Honda K24 Connecting Rods Main Sizes

Center to Center Length: 151.99mm/5.984"

Big End Bore Diameter: 51.006mm/2.008"

Big End Width: 19.8mm/0.780"

Small End Bore Diameter: 22.86mm /0.9"

Small End Width: 19.8mm/0.780"

Beam Style: H-beam

Performance Connecting Rod for Honda K24 More Details

Material：Forged 4340 Steel

Copper bush Material：QAL10-3-1.5

Connecting Rod Bolt Diameter: 3/8"-1.600''L

Quantity :4pcs/set

Approximate Connecting Rod Weight: 495g/piece

Advertised Horsepower Rating: 550hp

Material: Forged 4340 steel

Connecting Rod Finish: Shot-peened, Polished

Pin: Bronze wrist pin bushings

Wrist Pin Style: Floating

Cap Retention Style: Cap screw

Weight Matched Set: Yes ,Balanced +/- 1g

Magnafluxed: Yes

Private Label: Yes ,available

Custom design: Yes, accept

Technical Requirements:
1. Multi stage heat treatment: Quenching with subsequent tempering to HRC33-38 hardness.
2. Shot peening for improved fatigue life.
3. The forging defect which will affect the performance is not allowed.
4. Torque: 75NM, 4 pieces/set.

Application

For Honda/Acura K24 K24A1 K24A2 K24A4 K24A8 2.4L
for Honda CRV 2.4L 02-06 , K24A1
for Acura TSX 2.4L 04-08, K24A2
for Honda ACCORD 2.4L 03-14, K24A4
for Honda Element 2.4L 03-06, K24A4
for Honda Odyssey 2.4L 03-08, K24A4
for Honda Element 2.4L 07-11, K24A8
for Honda Odyssey 2.4L 08-14, K24A8
for Honda Accord (USDM) 2.4L 06-07, K24A8
