Bealead is a first manufacturer down filling machine and now is the top automatic down filling machine provider in china by offering products that are practical, innovative and come with first-class quality coupled with unparalleled customer experience and services.
Totally this model has four working stations, double in one side so it allows 4 workers operating at the same time. Module design, applied for different requirements. Down garment filling machine has advanced technology.Cost reduction, enhancing productivity with down stuffing machine.
With module design, x high output down filling machine is customized for each customer.
Applied for both down and fiber, X model can be automatic down filling machine as well as automatic fiber filling machine, .
User friendly, customize scales and filling ports of down jacket filling machine.
Brand: Bealead
Model: DF-4403X
Composed by: 1 feeding unit and 4 weighing units/ filling station
Filling Pipes: 4
Scales by filling pipe: 4
Fillings by hour: 1200-1600 lattices
Application: Apparel, Commodity, Textiles
Material Application: 50%- 90% down
Weight: 920kg
Filling Storage: 12kg
Weighing Range: 0.2g- 20g
Accuracy: 0.01g
Feeding Unit Size: 2.1* 0.8* 2.1m
Weighing Unit Size: 1.8* 0.6* 0.95m
Min. Site Area: 5m* 6m
|
Voltage |
220V |
Air Tank |
≥1m³ |
| Air Pressure |
0.6- 0.8MPa |
Air Compressor Power |
7.5KW |
| Min. Air Pressure |
0.5MPa |
Air Compressor Exhaust |
≥1m³/min |
| Max. Power |
2.5KW |
Air Monitoring System |
√ |
| PPR Pipe |
1 inch |
Down Returning System |
√ |
| Pipe Distance |
≤20m |
Humidity Control System | √ |
ChangShu Bealead Automatic Machine Co.,LTD, located in changshu, jiangsu ,china. Close to ShangHai Port, driving for 1.5hours, transportation convenient.
Our company is R&D manufacturer of intelligent device for clothing production. We are in leading
position in Down feather filling area, covered most of Chinese market, Bosideng, Luo Lai, UNI QLO, are our customers.
We also have agents overseas, and more than 20 technicians for after sales service. They could answer you and service you at the first time you need.
Our Factory
Exhibitions
CE Certificate
