Product details

1050 aluminium Coil is commonly used in some places that require high corrosion resistance and formability but not high strength. 1050 aluminum coil is also industrial aluminum. For example, A typical application is the manufacture of chemical industry containers. In addition,1050 aluminum alloy is used for lithium battery soft connection, pole material, explosion-proof valve, PS board base, heat sink, signage, lamp, reflector, etc.

All in all, 1000 series aluminum alloy coil has Less Tensile strength/ higher Al content/less other alloy. 1000 series aluminum coil is mainly used for signs, billboards, wall decoration, kitchen utensils, chemical equipment, electronic devices and other products that do not require high strength.

No.	Alloy States
		Chemical composition.%
		Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn		Ti	Zr	Other		AI
		Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn		Ti	Zr	Single	Total	AI
1	3003	0.6	0.7	0.05-0.20	1.0-1.5	-	-	-	0.1	-	-	-	0.05	0.15	Rem	-
2	4032	11.0-13.5	1	0.50-1.30	-	0.8-1.3	0.1	0.50-1.30	0.25	-	-	-	0.05	0.15	Rem	-
3	4043	4.5-6.0	0.8	0.3	0.05	0.05	-	-	0.1	-	0.2	-	0.05	0.15	Rem	-
4	4047	11.0-13.0	0.8	0.3	0.15	0.1	-	-	0.2	-	-	-	0.05	0.15	Rem	-
5	5052	0.25	0.4	0.1	0.1	2.2-2.8	0.15-0.35	-	0.1	-	-	-	0.05	0.15	Rem	-
6	5754	0.4	0.4	0.1	0.5	2.6-3.6	0.3	-	0.2	Mn+Cr:0.1-0.6	0.15	-	0.05	0.15	Rem	-
7	5182	0.2	0.35	0.15	0.20-0.50	4.0-5.0	0.1	-	0.25	-	0.1	-	0.05	0.15	Rem	-
8	5083	0.4	0.4	0.1	0.40-1.0	4.0-4.9	0.05-0.25	-	0.25	-	0.15	-	0.05	0.15	Rem	LF4
9	6061	0.40-0.8	0.7	0.15-0.40	0.15	0.8-1.2	0.04-0.35	-	0.25	-	0.15	-	0.05	0.15	Rem	LD30

Alloy States	Thickness (mm)	Tensile strenght (Rm/Mpa)	Yield Strength (Rp0.2 Mpa)	Elongation A50(%)	Bending Radius
5052 H32	>0.20-0.50	210-260	130	5	0.5t
	>0.50-1.50			6	1.0t
	>1.50-3.00			7	1.5t
	>3.00-6.00			10	1.5t
5052 H34	>0.20-0.50	230-280	150	4	0.5t
	>0.50-1.50			5	1.5t
	>1.50-3.00			6	2.0t
	>3.00-6.00			7	2.5t
5052 H36	>0.20-0.50	250-300	180	3	1.5t
	>0.50-1.50			4	2.0t
	>1.50-3.00			5	3.0t
	>3.00-6.00			6	3.5t
5052 H38	>0.20-0.50	270	210	3	-
	>0.50-1.50			3	-
	>1.50-3.00			4	-

Aluminum Coil
