Micro-Nano Bubble Generator
Definition of Micro-Nano Aeration System
The Micro Nano Bubble Generator (Combined With Ion Exchanger ) Independently Developed By Loren Industry Co. Is a New Generation High Efficiency Environmental Protection & Water Environment Pollution Recover. Technology.
Being Familiar With a Various Characteristics Of Micro Bubbles Such As Its Negative Ions, Slow Moving Speed &The Equivalent Of Ozone Bubbles Can Play a Bactericidal Effect. it Can Replace The Current Domestic Bubble Generation Technology &Some Aeration Equipment,It Can Efficiently Realize Functions Such As Oxygen Boosting &Aeration, Air-Floating Separation, Oil-Water Separation, Oxidative Decolorization, Nitrogen &Phosphorus Removal.
Composition
The Micro-Nano Aeration System Consists Of Micro-Nano Bubble Generator, Diffusion Device, Snorkeling Device, Limit Device &Control Device.
Feature
-Combined with Ion Ex-changer Can Kill Algae & Weeds
-Optical Material : FRP, Steel, Plastic, FRP,Steel Concrete Structure
-Large Volume Micro Nano Bubbles
-High Oxygen Tolerance Rate
-Simple Structure
-High Treatment Efficiency
-Easy Assembly
-Stable Operation
-No Clogging Performance
-Low Operating Cost
-Low Energy Consumption
-Gas Source Optional: Air, Oxygen, Ozone, Nitrogen
-Combined with Ion Exchanger Can Kill Algae & Weeds
-Automatic Local/Remote Intelligent Control
Application
-Aquaculture
-Landscape Engineering
-River Improvement
-Water Reuse
- Sewage Treatment
-Air-Liquid Mixing, Etc., Combined With Different Inlet Air Sources (Such As, Etc.) A
-Minimal equipment
-Teaching Demonstration
-Small Scale Tests
- Pilot Experiment
- Integrated Treatment Unit
-Quick Large-Scale Purification Of Black-Odor River
Model & Specification
Main Parameter of The Micro Mano Bubble Generator
Model
Capacity
(m3/h)
Power
(Kw)
Dimension
(mm)
Comment
LNG-0.2
0.22
0.125
300*140*280
Potable Style 220V
LNG-2.0
2.0
0.30
600*300*400
Float Style or Floor Mounted , Can Optional Choose Aerator or Odor
LNG-4.0
4.0
0.55
600*300*600
LNG-6.0
6.0
0.75
600*500*600
LNG-10
10
1.1
600*500*800
LNG-20
20
2.2
980*540*1860
Float Style or Floor Mounted , Can Optional Choose Aerator or Odor or Chemical Dosing
LNG-30
30
3.0
980*540*1860
LNG-40
40
5.5
1200*600*1400
LNG-60
60
5.5
1200*600*1500
LNG-80
80
7.5
1200*600*1650
LNG-100
100
11
1200*600*1700
Floor Mounted , Can Optional Choose Aerator or Odor or Chemical Dosing
LNG-120
120
15
1800*1000*1800
LNG-160
160
18
1800*1000*1800
LNG-200
200
22
1800*1000*1800
Main Parameter of The Matching Aerator System
|
Model |
Capacity (m3/h) |
Power (Kw) |
Cover Area (m) |
Comment |
|
LSA-1.2 |
30 |
1.2 |
40 |
Surge Aerator |
|
LWA-1.2 |
30 |
1.2 |
40 |
Water Spray Aerator |
|
LWA-2.2 |
60 |
2.2 |
60 |
|
|
LIA-1.2 |
30 |
1.2 |
40 |
Impeller Aerator |
|
LOA-0.75 |
25 |
0.75 |
30 |
Ordinary SprayFountain |
|
LCA-0.75 |
30 |
0.75 |
30 |
ColorSprayFountain |
|
LOA-2.2 |
60 |
2.2 |
60 |
Ordinary SprayFountain |
|
LCA-2.2 |
60 |
2.2 |
60 |
ColorSprayFountain |
|
LMA-3.0 |
70 |
3.0 |
80 |
MicroPorous Aeration |
|
LMA-5.5 |
80 |
5.5 |
90 |
|
|
LTA-1.1 |
50 |
1.1 |
100 |
Thrust flow Aerator
|
|
LTA-1.5 |
80 |
1.5 |
130 |
|
|
LTA-2.2 |
150 |
2.2 |
160 |
|
|
LTA-3.0 |
200 |
3.0 |
180 |
|
|
LTA-4.0 |
280 |
4.0 |
200 |
|
|
LIE-3.0 |
100 |
3.0 |
70 |
Oxygen Ion Exchanger |
