Package Including:
H4 870mm Quadcopter drone * 1 set
2170 foldable propeller * 2 pairs
MK15 remote controller * 1 set
Note: The drone would be shipped for ready to fly drone, we assembled and tested the drone well, but when we ship the drone, we will move the landing gear for a better shipping.
Specification:
Wheelbase: 870mm
Arm pipe size: outdiameter 20mm
Top center plate material: 2.0mm thickness carbon fiber plate
Bottom center plate material: PDB board
Frame side plate material: Aluminum alloy
Landing gear pipe size: outdiameter 18mm
Weight: about 2.96kg (ready to fly drone weight without battery)
Frame kit size: 690mm*670mm*340mm
Frame foldable size: 370mm*405mm*340mm
Battery case size: 210mm*120mm*80mm
Drone Power System:
6S 5015 330KV motor * 4pcs
40A ESC * 4pcs
2170 foldable propeller * 2 pairs
CUAV V5+ pixhaw flight controller * 1 set
MK15 remote controller with FPV * 1 set
Drone Real Testing Data:
The hovering time is about 46 mintues (without any payload).
The hovering time is about 21 mintues (with 2kg payload).
Note: The drone is using V5+ flight controller, MK15 remote controller, 1pcs of 6S 16000mAh semisolid HD battery.
