Material Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape Bar,Pipe/tube,sheet/plate,Forging,Ring,Coil,Flange,Ribbon,Square pipe/bar,product processing
Grade Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;etc
Inconel 600/601/602CA/617/625/713/718/738/X-750;ETC
Incoloy: Incoloy 800/800H/800HT/825/925/926;etc
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044,etc
Monel: Monel 400/K500/R405,etc
Nitronic: Nitronic 40/50/60;etc
Nimonic: Nimonic 75/80A/90/A263 ;etc
Specification Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-50mm;Length 2000-5000mm
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
Product Characteristics
1.According to the preparation process can be divided into deformation superalloys,
casting superalloys and powder metallurgy superalloys.
2.According to the strengthening mode, there are solid solution strengthening type, precipitation
strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..
Inspection ISO,SGS,BV and so on.
Packaging All our products are packed, stored, transported according to the international regulation.Or as customer's requirement provide special packing.
Inconel 718
Features: Inconel 718 is a nickel-chromium-molybdenum alloy designed to resist a wide range of severely corrosive environments, pitting and crevice corrosion. This nickel steel alloy also displays exceptionally high yield, tensile, and creep-rupture properties at high temperatures. This nickel alloy is used from cryogenic temperatures up to long term service at 1200° F. One of the distinguishing features of Inconel 718’s composition is the addition of niobium to permit age hardening which allows annealing and welding without spontaneous hardening during heating and cooling. The addition of niobium acts with the molybdenum to stiffen the alloy’s matrix and provide high strength without a strengthening heat treatment. Other popular nickel-chromium alloys are age hardened through the addition of aluminum and titanium. This nickel steel alloy is readily fabricated and may be welded in either the annealed or precipitation (age) hardened condition. This superalloy is used in a variety of industries such as aerospace, chemical processing, marine engineering, pollution-control equipment, and nuclear reactors.
Chemical Composition
Ni | Cr | Fe | C | Mn | Si | Mo | Cu |
---|---|---|---|---|---|---|---|
50-55 | 17-21 | balance | 0.08 max | 0.35 max | 0.35 max | 2.8-3.3 | 0.3 max |
Co | Al | Ti | Nb | B | P | S |
---|---|---|---|---|---|---|
1.0 max | 0.20-0.80 | 0.65-1.15 | 4.75-5.50 | 0-0.006 | 0.01 max | 0.01 max |
Density and Melting point
Density | Melting point |
---|---|
8.24g/cm³ | 1260-1320 ℃ |
Mechanical Properties
Finish Condition | Tensile strength Rm N/mm² | Yield strength R P 0. 2N/mm² | Elongation (A 5%) Min | HB |
---|---|---|---|---|
Solution treatment | 965 | 550 | 30 | ≤363 |
