Cnc machine Key Type Drill Chuck ,Keytype Drill Chuck Application:
Recommended for light, medium and heavy-duty portable bench or floor mounted power tiils. Taper hole connection are mainly B10, B12, B16, B18, B22 and JT0, JT2, JT3, JT6, JT10, JT33 and other specifications. Threaded connection is mainly used for electric drill, drilling machine is mainly used for connecting taper hole.Drill chuck is
connected with the tool, is used to clamp the handle type tool
accessories. There are two connection ways: threaded connections and
taper connection. According to the specifications of the chuck now,
specifications of the main thread of the 3/8-24UNF, 1/2-20UNF, 5/8-16UN,
M12 * 1.25
Key Type Drill Chuck Specifications
1. light duty or heavy duty.
2. taper mounted or thread mounted.
3. Rang offer from 1mm-16mm
4. Max.10.000 RPM without further balance
5. Precision reach 0.02mm to 0.03mm
6. separate drill chuck or integrated drill chuck
Drill Chuck Features:
1. High precision threaded and tapered tightly mounts on the tools.
2. Sleeve, key hole and key are shaped by quenching.
3. Jaws are specifically engineered for tight tolerance production drilling.
4. Sleeve teeth and key holesare are shaped by cold pressing.
5. Drill Press Chuck Super precision and durable.
|
1. Thread Mount: Unf. Metric |
|||
|
Model |
Capacity |
Mount |
|
|
mm |
Inch |
||
|
J3110M |
1.0-10 |
1/32-3/8 |
3/8-24UNF |
|
J3110M |
1.0-10 |
1/32-3/8 |
1/2-20UNF |
|
J3113M |
1.0-13 |
1/32-1/2 |
1/2-20UNF |
|
2. Moese Taper Mount |
|||
|
Model |
Capacity |
Mount |
|
|
mm |
Inch |
||
|
J2110H |
1.0-10 |
1/32-3/8 |
B12 |
|
J2113H |
1.0-13 |
1/32-1/2 |
B16 |
|
J2516M |
3.0-16 |
1/8-5/8 |
B16 |
|
J2516M |
3.0-16 |
1/8-5/8 |
B18 |
|
J2116H |
1.0-16 |
1/32-5/8 |
B16 |
|
J2116H |
1.0-16 |
1/32-5/8 |
B18 |
|
J2120H |
5.0-20 |
3/16-3/4 |
B22 |
|
3. Jacquard Taper Mount |
|||
|
Model |
Capacity |
Mount |
|
|
mm |
Inch |
||
|
J2210H |
1.0-10 |
1/32-3/8 |
JT2 |
|
J2213H |
1.0-13 |
1/32-1/2 |
JT33 |
|
J2213H |
1.0-13 |
1/32-1/2 |
JT6 |
|
J2616M |
3.0-16 |
1/8-5/8 |
JT3 |
|
J2616M |
3.0-16 |
1/8-5/8 |
JT33 |
|
J2616M |
3.0-16 |
1/8-5/8 |
JT6 |
|
J2216AH |
1.0-16 |
1/32-5/8 |
JT3 |
|
J2220 |
5.0-20 |
3/16-3/4 |
JT3 |
