Large Diameter Plastic Drain Pipe
Plastic Pipes for Water
Structure: Steel mesh skeleton rtp for coal is composed of high molecular functional polyethylene resin, flame retardant and static conductive double anti masterbatch, 1-4 layers of static conductive high-strength steel wire, impact resistant polyethylene resin and flame retardant and static conductive double anti masterbatch.
Application: Large Plastic Culvert Pipe used in coal mine water supply and drainage, grouting and other transportation systems
Temperature range: 0 ℃ ~ 60 ℃
Standard: CJ / t189-2007 MT / t181-1988 SY / t6662 2-2020 Q/XXCJ282-2021B
Characteristics: Colored High Density Polyethylene Pipe is suitable for the operation of water-based liquid conveying system in coal mine
Appearance: the appearance is black smooth
| Product code |
Nominal
Outer diameter
mm
|
Nominal pressure
Grade
MPa
|
Nominal outside diameter
Limit Deviation
mm
|
Minimum
Wall thickness
mm
|
Blasting
Fusion
MPa
|
Minimum Bend
Radius
mm
|
Reference
Weight
kg
|
| 609-225-3.5 | 225 | 3.5 |
+2.50
|
12.5+2.2 | 10.5 | 2800 | 10.23 |
| 609-250-0.8 | 250 | 0.8 |
+2.50
|
8+1.5 | 2.4 | 4000 | 6.94 |
| 609-250-1.0 | 250 | 1 |
+2.50
|
10.5+2.0 | 3 | 4000 | 8.83 |
| 609-250-1.25 | 250 | 1.25 |
+2.50
|
10.5+2.0 | 3.75 | 4000 | 9.12 |
| 609-250-1.6 | 250 | 1.6 |
+2.50
|
12+2.2 | 4.8 | 4000 | 10.63 |
| 609-250-2.0 | 250 | 2 |
+2.50
|
12+2.2 | 6 | 4000 | 11.22 |
| 609-250-2.5 | 250 | 2.5 |
+2.50
|
12.5+2.2 | 7.5 | 4000 | 12.01 |
| 609-250-3.5 | 250 | 3.5 |
+2.50
|
13+2.2 | 10.5 | 4000 | 12.93 |
| 609-315-0.8 | 315 | 0.8 |
+2.70
|
9.5+1.5 | 2.4 | 5500 | 12.5 |
| 609-315-1.0 | 315 | 1 |
+2.70
|
11.5+2.0 | 3 | 5500 | 13.5 |
| 609-315-1.25 | 315 | 1.25 |
+2.70
|
11.5+2.0 | 3.75 | 5500 | 15.2 |
| 609-315-1.6 | 315 | 1.6 |
+2.70
|
13+2.5 | 4.8 | 5500 | 16.4 |
| 609-315-2.0 | 315 | 2 |
+2.70
|
13+2.5 | 6 | 5500 | 22.6 |
Application Scenarios
