solar power system home applies to diversified loads because its digital design, pure sine wave output and excellent
over-current protection can withstand the loads with a large starting current solar power system for home using is provided
with independent solar three-stage charge management to improve charge efficiency of its battery and realize a longer
lifespan solar power system home provides universal 5V DC-USB output port and 12V DC output to DC applicances, and
AC power supply to be widely applied to small solar power generation occasions including families, schools, street
monitoring, forest monitoring,industrial and mining enterprises, frontier defense sea islands, pasturing areas,etc.
|
Mode: AL
|
0.3kW/12V
|
0.5kW/12V
|
0.5kW/24V
|
1kW/24v
|
1.5kW/24V
|
|
|
|
Battery voltage
|
12v
|
24v
|
|||
|
Built-in battery specification
|
1*55Ah/12V
|
2*55Ah/12V
|
4*55Ah/12V
|
|||
|
Rated power
|
300W
|
500W
|
500W
|
1000W
|
1500W
|
|
|
Output voltage
|
110/220VAC
|
|||||
|
Output frequency
|
50/60HZ
|
|||||
|
Output waveform
|
pure sine wave
|
|||||
|
a mains supply
|
Rated voltage
|
110/220V AC-*("*"mean an optional function)
|
||||
|
Charge current
|
10A(maximum)-*(*means an optional function)
|
5A (maximum)-*(*means an optional function)
|
||||
|
|
Maximum power
|
≤25V
|
≤50V
|
|||
|
Voltage of overcharge protection
|
10-25V
|
20-50V
|
||||
|
Rated charge current
|
30A
|
|||||
|
Maximum power
|
360Wp
|
720Wp
|
||||
|
Voltage of overcharge protection
|
14.2V
|
28.4V
|
||||
|
Voltage of overcharge recovery
|
14.0V
|
28.0V
|
||||
|
Voltage of floating charge
|
13.7V
|
27.4V
|
||||
|
|
Voltage of high-voltage protection
|
16V
|
32V
|
|||
|
Voltage of high voltage recovery
|
15.2V
|
30.4V
|
||||
|
Voltage of low voltage recovery
|
12.6V
|
25V
|
||||
|
Voltage of lower voltage protection
|
11V
|
22V
|
||||
|
5V DC USB output port
|
2one/max 2A
|
|||||
|
12V DC output port
|
2 DC ports + backboard 12V terminal block (maximum 8A)
|
|||||
|
Starting temperature of the exhaust fan
|
>45°C
|
|||||
|
Ambient temperature for operation
|
0 to 40°C
|
|||||
|
Ambient temperature for storage
|
-25 to 55°C
|
|||||
|
Operation/storage condition
|
0-90% (no condensation)
|
|||||
Portable Solar Power System home
Certifications
Q1: What is the warranty of your product?
A1: Quality warranty for 12 months; parts will be shipped free during warranty period.
Q2: Can you do OEM?
A2: Yes, we can offer the OEM service.
Q3: What is your delivery time?
A3: Within 5 day after receive advanced payment.
Q4: What minimum order do you require?
A4: 1 piece.
If you are interested in the product, contact 2bvideo.com for more information for more information
