Our company:
Ningbo Langsun Tungsten Carbide Co., Ltd. is equipped with the most professional tungsten carbide technology researchers in China. We constantly upgrade our machining technologies every year. Our company specializes in machining tungsten related products and has many cooperative manufacturers, so we can produce any product made from tungsten carbide.
Material composition:
Tungsten carbide material specification
Grade
Binder (Wt %)Cobalt
Density (g/cm3)
Hardness (HRA)
TRS (>N/mm²)
Grain Size(μm)
YG6
5.8-6.3
14.6-15.0
89.5-91
1800
0.8-2.0
YG6X
5.8-6.3
14.4-14.7
90.5-91.5
1650
0.6-1.0
YG8
7.5-8.2
14.4-14.7
89.0-90.5
2200
1.0-1.5
YG11
11.0-11.5
14.2-14.4
87.0-88.5
2800
1.0-2.0
YG11C
11.0-11.5
14.2-14.4
86.0-88.0
3000
1.0-2.5
YG15
14.5-15
13.9-14.0
86.0-88.0
3300
1.0-2.0
YG20
20.0-20.5
13.2-13.5
84.0-85.0
3400
1.0-2.0
YG20C
20.0-20.5
13.2-13.5
83.0-85.0
3600
1.0-2.5
K05VF
4.5-5.0
14.6-15.0
92.5-93.0
1500
0.6-1.0
K10VF
5.5-6.2
14.5-14.7
91.5-92.5
1550
0.6-1.0
K20VF
7.5-8.0
14.5-14.7
90.5-91.5
1800
0.6-1.0
Value:
tungsten carbide has superb solidity, yet if tungsten carbide is refined utilizing brazing modern technology, the securing efficiency of the item will considerably boost. As a vital part for regulating circulation, Tungsten Carbide Valves have really rigorous criteria for air rigidity. Carbide Brazed has outstanding securing impacts and is an optimal product in the eyes of several consumers.
Highlights:
1. Advanced hardness and toughness
2. Extraordinary abrasion resistance
3. Premium virgin tungsten material
4. Great Customized service
Advantages:
Along with the above, the warmth resistance of Brazing Tungsten Carbide do without stating. Brazing modern technology itself calls for running at exceptional heat, and the end product's warmth resistance is extra immune to heats than average refined items. Several high-temperature parts of autos and water pumps call for making use of Carbide Brazed Parts to boost their life span.
If you are interested in the product, contact 2bvideo.com for more information for more information
The information of 2bvideo.com limited shown above is provided by the user or collected on the network. Video 2B does not guarantee the authenticity,accuracy and legitimacy of 2bvideo.com limited information. Video 2B does not involve legal relationships and disputes between users arising from transactions other than secured transactions on this website. Disputes shall be settled by you through negotiation. If you are the person in charge or relevant employee of this enterprise, if you find that the enterprise information is incorrect or want to manage thiscompany, please contact us jacklee1558@gmail.com, after you claim the enterprise, you can obtain management permission, publish supplyand demand information, bring consulting orders, and remove page advertisements.
Main Product:
ORIFICE RINGS AND BOTTOM SLEEVES,
TUNGSTEN CARBIDE SEAL RINGS,
TUNGSTEN CARBIDE VALVE AND SEAT ,
TUNGSTEN CARBIDE NOZZLE,
CARBIDE CENTRIFUGE TILES ,
CARBIDE WEAR PARTS
