Motorola DEP450 Wireless walkie talkie
Versatile and powerful, MOTOTRBO™ combines the best of two way radio functionality with the latest analog and digital technology. The MOTOTRBO portfolio offers the right device for the right user, from voice-only portables to feature-rich voice and data radios.
The rugged MOTOTRBO DEP™450 is available as dual mode analog/digital radio that offers all the benefifits of the latest technology – from superior audio to greater coverage to longer battery life. This affordable portable is compatible with advanced MOTOTRBO features you'll fifind are business-essential, for example a transmission can be interrupted to prioritize critical communications.
Now you can improve the effificiency of your operation with easy-to-use voice communication that's right for you.
|
General |
||||
|
|
VHF |
UHF BAND1 |
UHF BAND 2 |
350 |
|
Channel Capacity |
32 |
|||
|
Typical RF Output Low Power High Power |
1 W 5 W |
1 W 4 W |
1 W 4 W |
1 W 4 W |
|
Frequency |
136-174 MHz |
403-470 MHz |
450-527 MHz |
350-400 MHz |
|
Radio Dimensions (H x W x D) with battery: NiMH 1400mAH Slim Li-Ion 1600mAH Li-Ion 225 0mAH |
5.0 x 2.4 x 1.7 in (127.7 x 61.5 x 42.0 mm) 5.0 x 2.4 x 1.5 in (127.7 x 61.5 x 39.0 mm) 5.0 x 2.4 x 1.8 in (127.7 x 61.5 x 44.0 mm) |
|||
|
Weight with battery: NiMH 1400mAH Slim Li-Ion 1600mAH Li-Ion 225 0mAH |
14.3 oz (406 g) 12.1 oz (341 g) 12.2 oz (346 g) |
|||
|
Battery |
||||
|
Power Supply |
7.5V (Nominal) |
|||
|
NiMH (1400 mAh) Battery |
Digital: 11.5 hrs |
|||
|
Li-Ion Slim (1600 mAH) Battery |
Digital: 13.5 hrs |
|||
|
High Cap Li-ion (225 0 mAH) Battery |
Digital: 19 hrs |
|||
|
FCC Description |
ABZ99FT3092 |
ABZ99FT4094 |
N/A |
|
|
Receiver |
||||
|
Frequency |
136-174 MHz |
403-470 MHz |
450-527 MHz |
350-400 MHz |
|
Channel Spacing |
12.5 kHz / 20 kHz / 25 kHz |
12.5 kHz / 25 kHz |
||
|
Frequency Stability (-30°C, +60°C, +25°C Ref) |
± 0.5 ppm |
|||
|
Analog Sensitivity (12 dB SINAD) |
0.3 uV / 0.22 uV (typical) |
|||
|
Digital Sensitivity (5% BER) |
0.25 uV / 0.19 uV (typical) |
|||
|
Intermodulation (TIA603D) |
70 dB |
|||
|
Adjacent Channel Selectivity TIA603A 1T: Adjacent Channel Selectivity TIA603C & TIA603D (2T): |
60dB @ 12.5kHz 45dB @ 12.5kHz |
|||
|
Spurious Rejection (TIA603D) |
70 dB |
|||
|
Rated Audio |
0.5 W (Internal) |
|||
|
Audio Distortion @ Rated Audio |
5% (3% typical) |
|||
|
Hum and Noise |
-40 dB @ 12.5 kHz -45 dB @ 20/25 kHz |
-40 dB @ 12.5 kHz -45 dB @ 25 kHz |
||
|
Audio Response |
TIA603D |
|||
|
Conducted Spurious Emissions (TIA603D) |
-57 dBm |
|||
|
Transmitter |
||||
|
Frequency |
136-174 MHz |
403-470 MHz |
450-527 MHz |
350-400 MHz |
|
Channel Spacing |
12.5 kHz / 20 kHz / 25 kHz |
12.5 kHz / 25 kHz |
||
|
Frequency Stability (-30°C, +60°C, +25°C Ref) |
± 0.5 ppm |
|||
|
Low Power Output |
1W |
1W |
1W |
1W |
|
High Power Output |
5W |
4W |
4W |
4W |
|
Modulation Limiting |
± 2.5 kHz @ 12.5 kHz / ± 4.0 kHz @ 20 kHz ± 5.0 kHz @ 25 kHz |
± 2.5 kHz @ 12.5 kHz ± 5.0 kHz @ 25 kHz |
||
|
FM Hum and Noise |
-40 dB @ 12.5 kHz -45 dB @ 20/25 kHz |
-40 dB @ 12.5 kHz -45 dB @ 25 kHz |
||
|
Conducted / Radiated Emission |
-36 dBm < 1 GHz / -30 dBm > 1 GHz |
|||
|
Adjacent Channel Power |
60 dB @ 12.5 kHz 70 dB @ 20/25 kHz |
60 dB @ 12.5 kHz 70 dB @ 25 kHz |
||
|
Audio Response |
TIA603D |
|||
|
Audio Distortion |
3% (typical) |
|||
|
4FSK Digital Modulation
|
12.5 kHz Data: 7K60F1D and 7K60FXD 12.5 kHz Voice: 7K60F1E and 7K60FXE Combination of 12.5 kHz Voice and Data: 7K60F1W |
|||
|
Digital Vocoder Type |
AMBE +2™ |
|||
|
Digital Protocol |
ETSI TS 102 361-1, -2, -3 |
|||
