QM IP66 single phase 6kW-10kW on-grid inverter with 3 MPPTs supports Bluetooth communication, making it easier to set and monitor inverter parameters. It has a low PV start-up voltage to achieve earlier power generation and has a high conversion efficiency of up to 98.6%.
Our PV company specializes in the installation and maintenance of photovoltaic solar panels, offering a comprehensive solar panel system for residential and commercial properties. We utilize cutting-edge technology such as mono perc solar panels and bifacial solar panels to maximize energy generation and efficiency. Whether you need a small-scale residential installation or a large-scale commercial solar panel project, our team is equipped to meet your specific needs.
Contact information:
|
Model
|
QM-3P5KEG-Pro
|
QM-3P6KEG-Pro
|
QM-3P8KEG
|
QM-3P10KEG
|
|
Input (PV)
|
||||
|
Max. Input Voltage (V)
|
1100
|
|||
|
Start-up Input Voltage (V)
|
120
|
|||
|
MPPT Voltage Range (V)
|
100~1080
|
|||
|
Max. Input Current (A)
|
18+18+18
|
|||
|
Max. Short Circuit Current (A)
|
22+22+22
|
|||
|
Number of MPPTs
|
3
|
|||
|
String Number per MPPT
|
1+1+1
|
|||
|
Output(Grid)
|
||||
|
Rated Output Power (kW)
|
5
|
6
|
8
|
10
|
|
Max. Output Apparent Power (kVA)
|
5
|
6
|
8
|
10
|
|
Max. Output Active Power (kW)
|
5
|
6
|
8
|
10
|
|
Rated AC Voltage (V)
|
220/230/240, L+N+PE
|
|||
|
AC Voltage Range (V)
|
277~460(adjustable)
|
|||
|
Max. Output Current (A)
|
7.25
|
8.7
|
11.6
|
14.5
|
|
Rated Grid Frequency (Hz)
|
50/60
|
|||
|
Grid Frequency Range (Hz)
|
45~55/55~65
|
|||
|
Power Factor
|
>0.99, 0.8 leading~0.8 lagging
|
|||
|
THDi
|
<3%
|
|||
|
DC Current Injection
|
<0.5%ln
|
|||
|
Efficiency
|
||||
|
Max. Efficiency
|
98.6%
|
|||
|
European Efficiency
|
98.3%
|
|||
|
Protection
|
||||
|
Ground Fault Monitoring
|
Support
|
|||
|
Output Over Voltage Protection
|
Support
|
|||
|
Anti-islanding Protection
|
Support
|
|||
|
Intergrated AFCI
|
Optional
|
|||
|
DC Reverse Pritection
|
Support
|
|||
|
Surge Arrester
|
DC Type II/ AC Type III
|
|||
|
General
|
||||
|
Topology
|
Transformerless
|
|||
|
Ingress Protection
|
IP66
|
|||
|
Cooling
|
Natural cooling
|
|||
|
Operating Temperature Range (°C)
|
-25~+60 (>45 derating)
|
|||
|
Relative Humidity Range
|
0-100% (no condensing)
|
|||
|
Max. Operating Altitude (m)
|
3000
|
|||
|
Noise Emission (dB)
|
20
|
|||
|
Dimension (mm)
|
411Wx401Hx162D
|
|||
|
Weight (kg)
|
15
|
|||
|
Display
|
Wireless, APP, LCD
|
|||
|
Communication
|
WiFi (2.4G), 4G, GPRS, Bluetooth, RS485
|
|||
|
Certification
|
||||
|
Safety Standard
|
IEC62109-1/-2
|
|||
|
EMC Standard
|
IEC61000-1/-2/-3
|
|||
|
Grid Code
|
AS4777.2, EN50549-1, G98, G99, ABNT NBR16149, ABNT NBR16150, VDE4105, CEI 0-21, RD1699
|
|||
|
Warranty
|
5 Years
|
|||
