LHS Series Hydrocyclone & Cyclone Separator
Definition of Precision Water Treatment Cyclone Desander
LHS Series Hydrocyclone Separator is a Main Machine to Separate Large Slurry or Large Grit or Oil & Grease In The Water Through Gravity or Pressurized Power in Form of Pipe Style or Cylindrical Styles . It Integrated Swirling and Filtration
Feature and Characteristic of Scale Reduction Water and Sand Separation Machine
-Simple Structure
-Easy Operation
-Reliable and Safe Performance
-Nearly No Needing Maintenance
-Large Capacity with Small Room
-Can Tidy the Grit or Sand Without Interrupting Water Supply
-With Little Purifying Resistance
-Precise Filtration With No Secondary Pollution
-High Sand Removal Ratio and Efficiency
-Back Washing Valve Can Auto Clean Its Filtration Mesh
-Only 5 Seconds Short Back Washing Time
Applicant Field of Groundwater Well Water Grit Collector Desander
- Water Source Hot Pump System
-Cooling Water for Center Air Conditioner
-Cooling Water System
-Winter Hot-Cold Circulated Water System
-Industrial Cooling Water System
-River Water
-Well Water Desander
-Coal Washing Water
-Industrial Mineral Separation
-Liquid Outgassing
-Steel Water
-Power Plant
-Chemistry
-Waterworks
-Sea Water
-Brackish Water
-Food Industry
-Pharmacy
-Environmental Protection
-Agriculture
-Other Water Treatment Fields
Technique Data
-Remove Sand Grain Size:＞0.1mm
-Raw Water Turbidity:≥300 NTU
-Outlet Water Turbidity:≤10 NTU
-Water Head Lost: <0.02 Mpa
-Water Inlet Pressure:≤0.25Mpa
-Pressure Lost: 0.028Mpa
-Smooth Sand Discharge
Working Principle
As per The Settling Density Difference of different Materials In Water To achieve solid liquid Separation Under The Function of Centrifugal Force ,The centripetal buoyancy and fluid drag, In Some Condition , The More Higher of The Filter Inlet Water Pressure, The Higher Efficiency of the Sand Removal Ratio. It Can Also Be Run with Multiple Sets Combined Together.
Working Process Normally
A. Raw Water→Swirl Desander→Security Filter→Water Storage Pool →User
B. Starch Slurry Water→Swirl Desander→Security Filter→Sedimentation Pool
Model Selection and Parameter Data
|
Model |
Capacity (M3) |
Max grain size (mm) |
Separation Size (µm) |
Dimension(mm) |
Sand Removal Ratio |
|
LHS-6 |
6 |
1.5 |
30-70 |
￠160*700 |
>96% |
|
LHS-9 |
9 |
1.5 |
30-70 |
￠160*800 |
>96% |
|
LHS-12 |
12 |
2.0 |
40-100 |
￠220*1000 |
>96% |
|
LHS-15 |
15 |
3.0 |
40-100 |
￠280*1100 |
>96% |
|
LHS-20 |
20 |
3.0 |
40-100 |
￠320*1100 |
>96% |
|
LHS-25 |
25 |
3.0 |
40-100 |
￠320*1200 |
>96% |
|
LHS-30 |
30 |
3.0 |
40-100 |
￠320*1300 |
>96% |
|
LHS-35 |
35 |
6.0 |
50-150 |
￠400*1400 |
>96% |
|
LHS-40 |
40 |
6.0 |
50-150 |
￠400*1500 |
>96% |
|
LHS-50 |
50 |
6.0 |
50-150 |
￠400*1600 |
>96% |
|
LHS-60 |
60 |
10 |
74-200 |
￠500*1500 |
>96% |
|
LHS-70 |
70 |
10 |
74-200 |
￠500*1500 |
>96% |
|
LHS-80 |
80 |
10 |
74-200 |
￠500*1550 |
>96% |
|
LHS-90 |
90 |
16 |
80-230 |
￠600*1600 |
>96% |
|
LHS-100 |
100 |
16 |
80-230 |
￠600*1700 |
>96% |
|
LHS-115 |
115 |
16 |
80-230 |
￠600*1800 |
>96% |
|
LHS-130 |
130 |
16 |
80-230 |
￠600*1900 |
>96% |
|
LHS-145 |
145 |
16 |
80-230 |
￠600*2000 |
>96% |
|
LHS-160 |
160 |
20 |
90-260 |
￠700*1700 |
>96% |
|
LHS-175 |
175 |
20 |
90-260 |
￠700*1800 |
>96% |
|
LHS-190 |
190 |
20 |
90-260 |
￠700*1900 |
>96% |
|
LHS-205 |
205 |
20 |
90-260 |
￠700*2000 |
>96% |
|
LHS-225 |
225 |
25 |
100-290 |
￠800*1800 |
>96% |
|
LHS-240 |
240 |
25 |
100-290 |
￠800*1900 |
>96% |
|
LHS-255 |
255 |
25 |
100-290 |
￠800*2000 |
>96% |
|
LHS-270 |
270 |
25 |
100-290 |
￠800*2100 |
>96% |
|
LHS-285 |
285 |
25 |
100-290 |
￠900*1900 |
>96% |
|
LHS-300 |
300 |
25 |
100-290 |
￠900*2000 |
>96% |
|
LHS-315 |
315 |
25 |
100-290 |
￠900*2100 |
>96% |
|
LHS-330 |
330 |
25 |
100-290 |
￠900*2200 |
>96% |
|
LHS-340 |
340 |
30 |
120-350 |
￠1000*2000 |
>96% |
|
LHS-365 |
365 |
30 |
120-350 |
￠1000*2100 |
>96% |
|
LHS-375 |
375 |
30 |
120-350 |
￠1000*2200 |
>96% |
|
LHS-390 |
390 |
30 |
120-350 |
￠1000*2300 |
>96% |
|
LHS-405 |
405 |
30 |
120-350 |
￠1000*2400 |
>96% |
Note:The Above Data is only for Reference, Will Subject to our Final confirmation
