Product details

CLW GROUP TRUCK DFAC Duolika 10-12CBM Compression Garbage Truck

Garbage Truck Series:(From 4CBM to 22CBM brand JMC,DFAC,FAW,SHACMAN,FOTON,NISSAN)

1.4x4 drive high quality chassis special for exporting garbage trucks;

2.Inter-cooling turbo;

3.5-speed gear box

4. with power take off, air-brake.

5.Air-conditioner available.

6.Cab:Single row flat cabin (with air-conditioner)

Production enterprise information
Vehicle name:	CLW GROUP TRUCK DFAC Duolika 10-12CBM Compression Garbage Truck	Vehicle type:	Special vehicle Laws and regulations
Manufacturing place:	China	Type of licence:	The vehicle license plate classification standard
Announcement batch:	283	Release date:	20160428
product ID:	ZM5JM54K01M	Directory number:	(Seventeen)74
Chinese brand:	CLW GROUP TRUCK	English brand:
Announcement type:	CLW5165ZYSD5	Exempt from:	no
Enterprise name:	CLW GROUP TRUCK	fuel:	no
Business address:	The southern suburbs of Hubei Province, Suizhou city Zengdou District Chengli Automobile Industry Park	environmental protection:	no
Inspection instructions
Exemption:	no	Check the inspection period:
Announcement status
Announcement status:	effective	Effective date of announcement:	20160428
Announcement state description:	extend	change(extend)Record:
Main technical parameters
Outline dimension:	8240,8000,7690,745025003250(mm)	Cargo compartment size:	* *(mm)
Total mass:	15955(Kg)	Load quality utilization factor:	0
curb weight:	8900,9700(Kg)	Rated load quality:	6900,6100(Kg)
Trailer quality:	(kg)	Semitrailer saddle:
Cab:		Front passenger:	3(people)
Rated capacity:	(people)	Anti lock braking system:	Yes
Approach angle/Departure angle:	19/13(DEG)	The front suspension/Rear overhang:	1230/2510,1230/2270(mm)
Axle load:	5995/10000	Wheelbase:	3950,4500,4700(mm)
Axis number:	2	Maximum speed:	90(km/h)
Oil consumption:	26.0	Spring sheet number:	8/10+7
Tyre number:	6	Tire specifications:	9.00R20
Front track:	1858,1949	Rear wheel:	1806,1865
Brake front:		After braking:
Before system operation:		After the operation of the system:
Steering form:	Steering wheel	Starting method:
drive system:		Oil consumption(L/100Km):	26.0
VinVehicle identification code:	LGDXWA1LX x x x x x x x x x x x LGDXWB1PX x x x x x x x x x x x LGDXWA1RX x x x x x x x x x x x LGDXWB1RX x x x x x x x x x x x Laws and regulations
Engine parameters
Engine	Engine production enterprise	displacement(ml)	power(kw)
YC4EG170-50 YC4EG185-50	Guangxi Yuchai Machinery Limited by Share Ltd Guangxi Yuchai Machinery Limited by Share Ltd	4730 4730	125 136
Vehicle fuel parameters
Fuel type:	diesel oil	Based on standard:
Chassis emission standard:	GB17691-2005China V,GB3847-2005
Other
1Selection of the car3950and4500Two wheelbase chassis.2And with the optional chassis cab.3, the car has five optional flip style,A:Triangle bucket device,B:Hanging barrel device,C:Swing arm device,D:Large floor hopper device,E:No turning device. When choosingABCDtime,The vehicle length(mm)/Wheelbase(mm)/Rear overhang(mm)/curb weight(Kg)The corresponding relationship is:7690/3950/2510/8900,8240/4500/2510/9700;When choosingEtime,The vehicle length(mm)/Wheelbase(mm)/Rear overhang(mm)The corresponding relationship is:7450/3950/2270,8000/4500/2270.4Protective material:Q235carbon steel,Connection mode:The left and right side faces are welded and connected to the auxiliary beam by welding.,Rear protection is replaced by special equipment.5,ABSSystem manufacturer,Model :Jiaozuo Borui grams control technology Co. Ltd.,J ABS.Traveling data recorder with satellite positioning function.6Vehicle color, text spray and local details can be changed.7The relationship between engine and fuel consumption value is only(L/100km):YC4EG170-50/26.0.
Reflective marking parameters
Marking enterprise:	CLW GROUP TRUCK	Logo mark:	CLW GROUP TRUCK
Identification model:	TM1200-1,HW1400

Fuel consumption parameter
Urban working conditions	Suburban condition	Comprehensive value
32.4	26.3	26.0

EQ1165LJ9BDEChassis parameters

Dongfeng truck chassis|Dongfeng brandEQ1165LJ9BDETruck chassisDetailed parameters

Enterprise name:

Dongfeng Automobile Limited by Share Ltd

Chassis Model:

EQ1165LJ9BDE

Chassis class:

Two

Product name:

Truck chassis

Product trademark:

Dongfeng brand

Zip code:

441004

Directory number:

Specifications:

long:7020,7880,8277 wide:2380 high:2865,2885

Fuel type:

diesel oil

Based on standard:

GB17691-2005China V,GB3847-2005

Steering form:

Steering wheel

Axis number:

Wheelbase:

3950,4500,4700

Spring sheet number:

8/10+7

Tyre number:

Tire specifications:

9.00R20

Tread:

Front track 1858,1949 Rear wheel 1806,1865

Total mass:

15995

curb weight:

4460,4900

Trailer quality:

Semitrailer saddle:

Front passenger:

Close to the left corner:

19/13

Front suspension rear suspension:

1230/1840,1230/2150,1230/2347

Maximum speed:

90,80

picture:

Dongfeng truck chassis\|Dongfeng brandEQ1165LJ9BDETruck chassisEngine detail parameters
Engine model	Engine production enterprise	displacement(ML)	power(ML)
YC4EG170-50 YC4EG185-50	Guangxi Yuchai Machinery Limited by Share Ltd Guangxi Yuchai Machinery Limited by Share Ltd	4730 4730	125 136
Identification code:	LGDXWA1LX x x x x x x x x x x x LGDXWB1PX x x x x x x x x x x x LGDXWA1RX x x x x x x x x x x x LGDXWB1RX x x x x x x x x x x x
Other:	YC4EG170-50Engine maximum net power:122(KW),YC4EG185-50Engine maximum net power:131(KW).ABSSystem manufacturer,Model :Jiaozuo Borui grams control technology Co. Ltd.,J ABS.Traveling data recorder with satellite positioning function.Optional speed limit device,Maximum speed is80km.The optional front exhaust pipe,The optional front disc brake.As a dangerous goods transport vehicle chassis, the car is only installed selection4700Wheelbase
