Puff snack making machine is a new type of extruding food machine studied and developed by ourselves on the basis of learning
from advanced technology in the world so that its technical performance and quality of products both reach to the most advanced
in the world. This line will finish mixing, extruding, cutting, spraying, and producing in onepass operation automatically. This has
features of lots of types, flexible collocation, extensive applied materials, various products and easy operation.
| Model | Installed Power | Power Consumption | Output | Size |
| FT63 Puffing Snacks Process Line | 150kw |
110kw |
250-300kg/h | 23000x1500x2200mm |
|
FT75 Puffing Snacks Process Line |
186kw |
139.5kw |
300-500kg/h |
24000x2000x2800mm |
| FT95 Puffing Snacks Process Line |
295kw |
222kw |
800-1200kg/h |
31000x3500x4300mm |
|
FT65 Puffing Snacks Process Line |
84kw |
59kw |
120-150kg/h |
21000x1200x2200mm |
|
FT70 Puffing Snacks Process Line |
132kw |
92kw |
200-250kg/h |
23000x1500x2200mm |
|
FT85 Puffing Snacks Process Line |
239kw |
167kw |
300-500kg/h |
28000x3500x4300mm |
1.Raw materials:Corn powder,rice powder,wheat flour,soya flour and etc.
2.Shape:By changing the moulds and process technology,this line can produce core-filled snacks,
like chocolate filled bar,cream filled pillow,rice cake,cereal bar,sheet snacks etc.we can give you 6
shape with free.
3.Flow Chart:Flour Mixer | Screw Conveyor | Twin Screw Extruder | Core Filling Machine| Shaping Cutter
| Elevating Conveyor | Continuous Belt Dryer | Double Drum Flavoring Machine | Cooling Conveyor
4. Voltage: Three phases: 380V/50HZ, Single phase: 220V/50HZ, we can make it according to customers'
local
voltage of different countries.
5. Capacity: 120-150 KG/H, 200-250 KG/H,500-700KG/H,800-1000KG/H,400-500KG/H,800-1200KG/H
