With this dynamic evolution of MOTOTRBO digital two way radios, you're better connected, safer and more productive. The XiR M8600i Series is designed for the skilled professional who refuses to compromise. With high performance integrated voice and data, and advanced features for efficient operation, these next-generation radios deliver complete connectivity to your organisation.
CONNECTED
The MOTOTRBO XiR M8600i walkie talkie Series is a family of DMR-standard digital radios that delivers operations-critical voice and communications. Bluetooth® audio lets you talk without wires, integrated Wi-Fi enables remote software updates, and indoor and outdoor location-tracking capabilities give you total visibility of your resources. With support for trunking as well as legacy analogue technology, you can keep your organisation connected as it grows.
SAFE
Safeguard your staff with responsive push-to-talk technology. The quick access buttons on XiR M8600i radio repeater Series radios can summon help with one touch, using Transmit Interrupt to clear a channel when necessary. A range of safe driving accessories allow your workers to communicate hands -free, and Text-to-Speech technology helps your drivers keep their eyes on the road.
PRODUCTIVE
Text messaging and Work Order Ticketing simplify complex communications, and data capabilities support advanced applications. Featuring a high power audio amplifier, these radios deliver loud, clear speech, with background noise cancellation for better intelligibility. XiR M8600i Series radios are also ideal as a dispatch solution, with desktop microphones and a rugged, durable design for everyday use.
|
General |
|||
|
Band |
VHF |
350 |
UHF Band 1 |
|
Frequency |
136-174 MHz |
350-400 MHz |
403-470 MHz |
|
High Power Output |
25-45W |
1-40W |
25-40W |
|
Low Power Output |
1-25 W |
- |
1-25 W |
|
Channel Spacing |
12.5, 25 kHz |
||
|
Channel Capacity |
32 |
||
|
Dimensions (H x W x D) |
53 x 175 x 206 mm |
||
|
Weight |
1.8 kg |
||
|
Power Supply (Nominal) |
12 V |
||
|
Transmitter |
|||
|
4FSK Digital Modulation |
12.5 kHz Data: 7K60F1D and 7K60FXD, 12.5 kHz Voice: 7K60F1E and 7K60FXE, Combination of 12.5 kHz Voice and Data: 7K60F1W |
||
|
Digital Protocol |
ETSI TS 102 361-1, -2, -3, -4 |
||
|
Conducted/Radiated Emissions (TIA603D) |
-36 dBm < 1GHz, -30 dBm > 1GHz |
||
|
Adjacent Channel Power |
60dB (12.5 kHz channel), 70dB (25 kHz channel) |
||
|
Frequency Stability |
± 0.5 ppm |
||
|
Receiver |
|||
|
Analogue Sensitivity (12dB SINAD) |
0.3 uV |
||
|
Digital Sensitivity (5% BER) |
0.25 uV |
||
|
Intermodulation (TIA603D) |
VHF : 78dB UHF1, UHF2, 350, 800 : 75dB |
||
|
Adjacent Channel Selectivity, (TIA603A)-1T |
VHF : 65 dB (12.5 kHz channel), 80 dB (25 kHz channel) UHF1, UHF2, 350, 800 : 65 dB (12.5 kHz channel), 75 dB (25 kHz channel) |
||
|
Adjacent Channel Selectivity, (TIA603D)-2T & (TIA603C)-2T |
VHF : 50 dB (12.5 kHz channel), 80 dB (25 kHz channel) UHF1, UHF2, 350, 800 : 50 dB (12.5 kHz channel), 75 dB (25 kHz channel) |
||
|
Spurious Rejection (TIA603D) |
VHF : 80 dB UHF1, UHF2, 350, 800 : 75 dB |
||
|
Audio |
|||
|
Digital Vocoder Type |
AMBE+2™ |
||
|
Audio Response |
TIA603D |
||
|
Rated Audio |
3 W (internal speaker) 7.5 W (external 8 ohm speaker) 13 W (external 4 ohm speaker) |
||
|
Audio Distortion at Rated Audio |
3% |
||
|
Hum and Noise |
-40 dB (12.5 kHz channel), -45 dB (25 kHz channel) |
||
|
Conducted Spurious Emissions (TIA603D) |
-57 dBm |
||
|
Environmental |
|||
|
Operating Temperature |
-30 °C to +60 °C |
||
|
Storage Temperature |
-40 °C to +85 °C |
||
|
Electrostatic Discharge |
IEC 61000-4-2 Level 4 |
||
|
Dust and Water Intrusion |
IEC 60529 - IP54 |
||
|
Packaging Test |
MIL-STD 810C, D,E,F and G |
||
