Baoji Zhipu Non-Ferrous Metals Processing Co., Ltd.

 1 min year

Product details

Baoji Zhipu non-ferrous metals processing co., ltd was established in 2003 and specialized in deep processing of refractory metals field. In 13 years` time, we have been focusing on tungsten, Molybdenum and tantalum finish machining parts in vacuum application industry, especially on vacuum furnace, atmosphere furnace and high temperature furnace. We have accumulated quite experience and technology in technology research and development, furnace transformation, vacuum furnace structure technical exchange and refractory metals'deep processing technological exploration and have been to main supplier of vacuum furnace material and heating room. Now, Zhipu Company is awarded to high-tech enterprise, Shaanxi well-known trademark enterprise and is authorized by the world third party company---- TUV Rhineland Germany. So far, our total assets have 93 million Yuan and 117 employees, among of them, 8 senior engineering and technical employees, 36 intermediate technical employees and more than 63% employees above college education degree.

In recent years, according to change and demand of new market, company have cooperated with domestic university and research institute and established technology research and development center, aiming at in research of photovoltaic equipment, ynthetic sapphire equipment and refractory metals` furnaceparts. Our products have various series branch: tungsten, molybdenum and tantalum parts in all kinds of high temperature furnace; Tungsten Wire rope and other series products for pulling method of all kinds of semiconductor crystal growth; tungsten, molybdenum, tantalum and niobium refractory metals` plates, bars, wires,Niobium Boat, tubes; various diaphragms and electrodes. Now, we have 20 patents and some of technologies and products are filled of domestic blank.

Products lists:

1. Tungsten, molybdenum and tantalum parts and heating room series products in all kinds of high temperature furnace;

2. Tungsten, Molybdenum Products in crystal furnace of PV industry;

3. Various single crystal furnaces thermal field tungsten and molybdenum products in sapphire industry;

4. Diaphragms and electrodes products in various instruments.

Tungsten ProductsTantalum Niobium Products Other Products
Forged And Rolled Niobium Boat

Is Tungsten Rhenium Filament Surface Area Scrap Suppliers Source Synonym Spectroscopy Significato Temperature

The tungsten wire rope of "ZHIPU"brand, is also called tungsten flexible shaft, the lifting wire rope , which is

one of the highest quality products with a patent for invention in ZHIPU company,Pure Niobium Target, our tungsten wire rope pulls

well, the rope head is the company's core patent products, technology research and development has a wealth

of experience in 15 years ,in the field of applications:aerospace, rare earth smelting, electric light source,

chemical equipment, medical equipment, metallurgical machinery, Good Stability Niobium Target, equipment, petroleum, smelting and other

industries, we constantly explore and timely improveour technology, on the basis of this ,we have established

a good reputation with our customers, and have realized the mutual cooperation. The common purpose of profit.

Wire rope purity	≥99.95%
Grade	W1, W2
Density	19.3g/cm3
Perpendicularity	＞89°
Standard	GB/T 3876-83
Specification	Φ1,Φ1.5,Φ1.8,Φ2.0,Φ2.5,Φ3,Φ3.5,Φ4
Technology	Cold rolled(Y), Hot rolled(R), Annealing treatment(M)
Appearance	Bright surface
Delivery time	Within 30 working days
Application	For silicon single crystal growth furnace lift system "soft shaft" use

Diameter specifications

Tungsten wire rope type	Diameter(mm)	Structure(Z type winding)	Bearing force indoor(kg)
Zp-w-1.0	Φ1.0	777	90±3%
Zp-w-1.8	Φ1.8	7194	200±5%
Zp-w-2.0	Φ2.0	7*19	250±5%
Zp-w-2.5	Φ2.5	7197	430±5%
Zp-w-2.5	Φ2.5	7*19	450±5%
Zp-w-3.0	Φ3.0	7*19	900±10%
Zp-w-4.0	Φ4.0	7*19	1200±10%

Product Name	Tungsten Wire
Material	Tungsten
Color	Silver White
Standard	ASTM GB/T 4181-1997
Tungsten wire rope application:	1.Monocrystalline silicon material production process used in photovoltaic industry, the growth furnace soft shaft lift system. 2.Used in semiconductor industry czochralski method single crystal materials in the production of flexible shaft. 3.For more than 1000 ℃ vacuum or atmosphere to protect the environment, using a fine wire rope linear or non linear tension bearing.
Specification:(unit:mm)	1.φ1 weave technology:7×7×7 2.φ1.8 weave technology:7×19×4 3.φ2.0 weave technology:7×19×4 7×19 4.φ2.5 weave technology:7×19×4 7×19 5.φ3.0 weave technology:7×19 6.φ3.5 weave technology:7×19 7.φ4.0 weave technology:7×19 If you have any special specification,please call us in time.
Thread	Weight, length
Used	single-crystal furnace parts
