Icom IC-F111 mobile radio
The Icom IC-F111 mobile radio is a versatile and reliable communication device perfect for various industries and applications. This handheld radio provides seamless and clear communication with its advanced features and durable design. Whether you are working in construction, security, or any other field that requires constant communication, this walkie talkie is an essential tool.
The IC-F111 is a portable radio that offers exceptional audio quality even in noisy environments, ensuring that every message is heard loud and clear. With its two-way radio capability, you can easily communicate with your team members or colleagues, enhancing productivity and efficiency on the job.
This Icom mobile radio is built to withstand tough conditions, featuring a rugged construction that can withstand drops, shocks, and vibrations. Its compact and lightweight design makes it easy to carry and operate, ensuring convenience and comfort during long hours of use. Whether
you need a reliable communication solution for your business or for outdoor activities, the Icom IC-F111 mobile radio is the perfect choice. Experience the power of seamless communication with this portable two way radio that guarantees reliable performance in any situation.
● Powerful 50W (VHF), 45W (UHF) Output
● 6 Prog. Buttons and Independent
Volume Knob
● 4W typ. Front-mounted Speaker
● 128 Memory Channels with 8 Memory
Banks
● 8-Character Alphanumeric Display
● Flexible Hanger Actions
● Built-in 2-Tone, 5-Tone, CTCSS, DTCS
Encoder & Decoder
● Advanced Multi 2-Tone/5-Tone Systems
(See overleaf for details)
● Standard DTMF Encoder and Optional
DTMF Decoder with ANI Function
● Programmable Wide/Narrow Channel
Spacing for Each Channel
● Optional Voice Scrambler, UT-109/UT-110
SPECIFICATIONS
• Frequency coverage :
IC-F111 136–174MHz
IC-F211 400–430MHz
440–490MHz
• Number of channels : 128 channels/8 banks
• Channel spacing : 12.5/25kHz
• PLL channel step : VHF 2.5, 3.125kHz
UHF 5, 6.25kHz
• Frequency stability : VHF ±5.0ppm
UHF ±2.5ppm
• Operating temp. range : –30˚C to +60˚C
• Power supply voltage : 13.6V DC
• Current drain (approx.) :
Tx VHF (50W)
14A
UHF (45W)
13A
Rx max. audio 1200mA
stand-by 300mA
• Antenna impedance : 50Ω (SO-239)
• Dimensions (W×H×D) : 150×40×167.5mm
• Weight : 1.1kg
• Output power : VHF 50W
(at 13.6V DC)
UHF 45W
• Max. frequency : ±5.0kHz (wide)
deviation ±2.5kHz (narrow)
• Spurious emissions : 70dB typ.
• Adjacent channel : 70dB (wide)
power 60dB (narrow)
• Microphone impedance : 600Ω (8-pin modular)
• Sensitivity : 0.25µV typ. (at 12dB SINAD)
• Squelch sensitivity : 0.25µV typ.
• Adjacent channel : 75dB typ. (wide)
selectivity 65dB typ. (narrow)
• Spurious response : 75dB
• Intermodulation : VHF 74dB typ.
UHF 75dB typ.
• Audio output power : 4W typ. at 10% distortion with a
4Ω load
• Ext. SP connector : 2-conductor 3.5 (d) mm/4Ω
