Loren LVD Serious Screw Discharge Sludge Volute Decanter
Waste Oil 3 Phase Horizontal Decanter Centrifuge Definition
Loren LVD Serious Horizontal Screw Centrifuge Is a Kind Of Screw Discharge Sedimentation Centrifuge Which Can Classify , Dehydrate and Clarify Solid Suspend Solid Phase Particle of 0.002-3mm. It Is Suitable For Separating Various Materials Under Different Working Conditions. Our Decanter Centrifuges Are Modular In Design And Can Be Used In a Wide Range Of Industries. Centrifuges Can Be Optimally Adjusted For Specific Applications. Applications Range From Sludge Dewatering To Classification Or Wet Classification To Solid Classification.
High Speed Industrial Horizontal Extraction Centrifuge Composition
It is Mainly Composed Of Drum, Screw, Differential System, Liquid Level Baffle, Drive System And Control System etc.
Feature and Advantage
-Large Aspect Ratio, High Speed With Various Angles Drum Cone
-The Feeding Screw Adopts Special Anti-Wear Measures
-Effectively Avoid The Double-Rotor High-Speed Rotation Resonance Area Phenomenon (Between 2mm/s And 4 Mm/s)
-Microcomputer Control System With Differential Speed And Torque That Can Be Automatically Adjusted With Changes In Material Concentration &Flow
-Clean Appearance
-No More Odour Generated
-Easy To Install& Operate
-Small Footprint
-Fit for Different Types of Sludge
-Selected Optional for Both Thickening & Dewatering
-Reduced Labour Cost
-More Process Flexibility Or Higher Levels Of Performance
Model Selection and Parameter Data of Horizontal Screw Centrifugal Dewatering Machine
|
Model |
Capacity (M3/h) |
Bowl Size DN*Length (mm) |
Bowl Speed (RPM) |
Main Power （ kw） |
Dimension L*W*H (m) |
|
LVD-250 |
0.5-3 |
250*900 |
5000 |
11/5.5 |
2.3*0.7*1.3 |
|
LVD-300 |
1-12 |
300*1350 |
3800 |
15 |
2.3*1.25*0.85 |
|
LVD-350 |
1-5 |
350*1500 |
3800 |
18.5/5.5 |
3.5*1*1.3 |
|
LVD-400 |
1-12 |
400*1800 |
3400 |
22/7.5 |
4*1*1.25 |
|
LVD-430 |
5-20 |
430*1800 |
3200 |
30/7.5 |
4.3*1*1.34 |
|
LVD-450 |
5-25 |
450*1800 |
3200 |
30/7.5 |
4.2*1.2*1.35 |
|
LVD-480 |
10-30 |
480*2000 |
3200 |
45/18.5 |
4.4*1.2*1.35 |
|
LVD-500 |
10-35 |
500*2200 |
3200 |
55/18.5 |
4.8*1.3*1.45 |
|
LVD-530 |
10-50 |
530*2280 |
2800 |
45/15 |
4.75*1.3*1.5 |
|
LVD-580 |
25-60 |
582*2800 |
3200 |
55/30 |
5.5*1.3*1.7 |
|
LVD-600 |
15-65 |
600*2400 |
2600 |
55/30 |
4.8*1.35*1.95 |
|
LVD-650 |
20-80 |
650*2600 |
2400 |
55/90 |
4.9*1.45*1.65 |
|
LVD-720 |
25-90 |
720*2500 |
2200 |
75/90 |
5*1.6*1.7 |
|
LVD-800 |
30-100 |
800*2560 |
2000 |
90/132 |
4.6*2.2*1.4 |
|
LVD-800 |
30-110 |
800*3200 |
2000 |
90/132 |
5.2*2.2*1.4 |
|
LVD-900 |
30-150 |
800*3200 |
1800 |
132/200 |
5.5*2.4*1.8 |
Working Principle
The drum and the screw rotate at a high speed in the same direction at a certain differential speed. The material is continuously introduced into the inner cylinder of the feeding screw from the feed pipe, and then enters the drum after being accelerated. Under the action of the centrifugal force field, the heavier solid phase is deposited on the wall of the drum. A layer of sediment is formed. The conveying screw continuously pushes the deposited solid phase to the cone end of the drum, and is discharged out of the machine through the slag discharge port. The lighter liquid phase forms an inner liquid ring, continuously overflows the drum from the overflow port at the large end of the drum, and is discharged out of the machine through the liquid discharge port.
Main Applicant for Both 2 Phase or 3 Phase Separation
-Waste Water Treatment
-Infrastructure Mud
-Food Processing
-Petrochemical
-Petroleum
-Waste Recycling
-Fish Processing
-Mineral Dressing
-Organic Chemicals
-Inorganic Chemical Industry
-Beverage Industry
-Organic Chemicals
-Polymer Industry
-Slaughter House
-Pharmacy
-Breeding Manure and Biogas Liquid
-Paint Powder, Kaolin, Plastic Scrap Recycling
