Product details

GUANGDONG GUANG YUAN an aluminum profiles manufacturer. was established in 1993, which is located in Sanshui District, Foshan City, Guangdong Province, China. We are a professional aluminum profiles manufacturer company integrating the research and development, production and sales of aluminium extrusion profiles. We are mainly specialized in the production of architectural aluminium profiles, decorative aluminum extrusion, heat sink aluminium extrusion, industrial aluminum profiles and special aluminium profiles for aerospace and military industries, aluminium door and window system, and aluminium furniture, etc.

Aluminium sliding window is windows made of aluminum profiles with frame and window leaves structures, divided into ordinary aluminium sliding window and thermal break aluminium sliding window. Aluminium sliding window are beautiful, sealed, and high in strength. They are widely used in the field of construction engineering. In home improvement, aluminum alloy doors and windows are often used to package balconies.

Aluminium sliding window is the most commonly used in the construction of doors and windows in buildings. Now, for this type of sliding windows, they also have a lot of their own performance characteristics during use. Let's take a look at what aspects of this type of windows and doors have in the process of use.

First of all, for this aluminium sliding window, it has one aspect of characteristics during use, that is, it will not occupy our indoor space during use, unlike some casement windows, When it is opened, it is often affected by space problems, and its lighting effect is also very good. It can allow more indoor lighting. From the appearance, the overall shape is also very beautiful.

Also, for this type of interior door and window, it is also very flexible to switch during use, because when it is installed, it also uses high-grade slide rails. It only needs to be pushed gently when it is closed, it is very flexible, and the force it receives is also very uniform in use, which is not prone to some damage.

In addition, for this type of interior doors and windows, the range in which it can be installed is also very wide. It can be installed and used in some residential communities, it can also be used in some public building facilities, and it can also be used in many commercial places, etc., we can see it in a lot of different places.

Product Name	Aluminium sliding window
Manufacturing Standard	AS2047
Quality Certificate	ISO 9001:2015, ISO 14001:2015, CQM Certification, SGS
Aluminium Profiles	6063-T5 high quality thermal/non-thermal break aluminium profiles
Profiles Thickness	1.4mm for windows, 2.0mm for doors
Surface Treatment	Anodizing, electrophoresis, powder coating, fluorocarbon, and wooden color
Color	Silver, champagne, bronze, white, charcoal, black, brown, grey and wooden colors
Glazing Type	tempered glazing, tinted glazing, frosted glazing, reflective glazing, laminated glazing and LOW-E glazing
Glazing Thickness	Single tempered glazing: 5mm, 6mm, 8mm, 10mm and 12mm
	Double tempered glazing: 4+12A+4mm, 5+9A+5mm, 5+12A+5mm, 5+15A+5mm, 5+19A+5mm and 6+12A+6mm
Mesh	Stainless steel security mesh, diamond mesh, aluminium security mesh, and fiberglass flyscreen
	Retractable screen, fixed screen and sliding screen
Sealing	Chinese famous brand silicone and EPDM strips
Hardware	KINLONG, HOPPE, HOPO, SIEGENIA AUBI, CMECH
Architrave	Depending on the customer’s requirements
Guarantee	10 years to 20 years
Application	Residential houses, commercial buildings, luxurious villas, modular houses, prefab houses and steel structure houses
MOQ	1 set
Packing Details	EPE foam packing and wooden crate packing
Payment Term	1) T/T: 30% of total value as deposit by T/T within 3 days to confirm the order, and the balance to be paid by T/T before loading the container.
	2) L/C: 30% of total value as deposit to be paid by T/T within 3 days to confirm the order, and the balance to be paid by L/C at sight after loading the container.
	3) Big order: Pay 30% of total value as deposit by T/T within 3 day to confirm the order, and the balance to be paid by T/T after delivery against the copy of B/L.
STRUCTURAL PARAMETERS
Profile Thickness	Frame Depth					Sash Width
2.0mm	138mm					90mm
PERFORMANCE PARAMETERS
Heat Insulation(m2·K)	Sound Insulation(DB)		Water Tightness(PA)	Air Tightness		Wind Load(KPa)
4W	45DB		700PA	4.5≤92>3.0		3.5≤P3>4.0
Level 4	Level 4		Level 6	Level 8		Level 8
SHIPMENT
Standard Loading Quantity		1*20GP			1*40HQ
		Max. length: 5.85 meters			Max. length: 12 meters
		200 square meters			400 square meters
Standard Loading Port		HUANGPU / NANSHA / YANTIAN / SHEKOU
Shipping Methods		Ocean shipment, air shipment, land transportation and multi-transportation, etc.

FAQ

1. Are you a manufacturer or a trading company?

--- We are aluminium extrusion company specialized in the production of aluminium profiles and aluminium windows since 1993. And you are warmly welcomed to visit our factory.

2.What kinds of surface treatments can your company complete?

--- We can complete different kinds of surface treatments including mill finish, anodizing, electrophoresis, powder coating, wooden color, fluorocarbon coating, polishing and brushed, etc.

3. Can you produce customized windows?

--- Yes, we can produce the windows as per customers’ window specifications.

4. What is the lead time for mass production?

--- The time for mass production is around 20~45 days.

5. How can you ensure high quality?

--- We use primary aluminium raw materials to make aluminium billets by ourselves, never mixing scrap to lower the cost.

--- Our QC are strict with final product inspection and only accept qualified products.

--- All the products are produced according international standard.
