Can PDLC Glass Be Used Instead Of Curtains And Blinds?
Privacy pdlc film has a decorative effect or hiding the contents of a room with patterns and colors. Smart dimming film has a masking effect and the blurriness makes it impossible to tell anything apart or peek into a room. Smart blind film is favored for their easy, stick-on method of application. Many people will only be able to see colors and vague shapes moving around if they come close enough on the other side of the room.
Dimming film can be used in exterior walls, Windows, skylights, ceilings, sunrooms, partition walls, etc. Privacy film provides a unique combination of sustainable control and safety. It can be controlled manually or automatically, and can be customized to the size, so it is very widely used.
|
P D L C F I L M
|
|
|
|
Test Items
|
High temperature experiment 70 °C, 240 h;
Low temperature experiment -20 °C, 240 h;
High temperature and high humidity experiment 60°C, 95% RH, 240 h;
High and low temperature shock test -20 °C, 30 min, 70 °C, 30 min (cycle 50 times).
|
|
|
Atomization Rate
|
Transparency is 96% when the magic glass film powered on;
Transparency is less than 4% when the smart film powered off.
|
|
|
180° Visible Light Transmittance
|
Transparency is 83% when the pet film powered on;
Transparency is more than 60% when the smart film roll powered off.
|
|
|
Application
|
Privacy Room,Projection,Silent Room,Fire Room,Window Advertising,Special Perspective Lift,Bank,Showcase,Bathroom,Vehicle Application,Hospital,Brand Store,Restaurant,Factory Floor,Dynamic Window Display,Control Room,......
|
|
|
Response Time (OFF-ON)
|
< 10ms
|
|
|
Power Consumption
|
5W/㎡
|
|
|
Operating Voltage (ON)
|
AC48V ~ 65V/50Hz
|
|
|
Energy Saving
|
Block more than 99% of the uv and more than 98% of the infrared, insulation performance reaches level 2 or above.
|
|
|
Safety
|
It has the advantages of safety glass, good impact resistance,eva film and laminated glass smart film firmly adheres the glass, so that
the smart glass can prevent debris from hurting people after being broken by impact. |
|
|
Control Methods
|
Manual switch, remote control, trigger control, voice control, APP control, timing control, remote network control, etc, can be
customized according to customer needs. |
|
