1.Vertical opening and closing mold and in-line screw injection for easyinlay and injection molding.
2.Multi section PID temperature control of material pipe, stepless speed regulation of feeding, stable forming.
3.Screen industrial control computer, simple operation, precise control and low failure.
4. Four column type with pedestal lifting, more stable large mold, more stable product quality.
5. The single slide plate can slide out of the mold for operation, and it is safer and more convenient to swing the parts to take the products.
| MODEL | UNIT | CY-550ST-PP | |||
| INJECTION UNIT | Screw Diameter | mm | 32 | 35 | 42 |
| lnjection Pressure | kg/cm² | 1907 | 1590 | 1110 | |
| Theoretical Shot Volume | cm³ | 112 | 134 | 194 | |
| Max.Shot Weight(Ps) | g | 103 | 123 | 178 | |
| Safe Shot Weight(Ps) | OZ | 3.6 | 4.3 | 6.2 | |
| Max.Shot Weight(PS) | cm³/sec | 50 | 60 | 87 | |
| Injection Rate | mm | 140 | |||
| Screw Speed Max. | rpm | 0-175 | |||
| Nozzle Comtact Force | tons | 5.5 | |||
| Nozzle Retraction Stroke | mm | 210 | |||
| Number of Temperature Control | 3 | ||||
| CLAMPING UNIT | Clamping Force |
tons
KN
|
55
550
|
||
| Platen Size | mm | 450×450 | |||
| Tiebar distance | mm | 470×280 | |||
| Min.Mold Height | mm | 250/200 | |||
| Opening Stroke | mm | 200 | |||
| Max.Open Daylight | mm | 450/400 | |||
| Ejetor Force | tons | 1.5 | |||
| Ejetor Stoke | mm | 55 | |||
| POWER/HEADING UNIT | Max.Hydaulic Pressure | kg/cm² | 140 | ||
| Pump Output | l/min | 43.2 | |||
| Oil Resservoir Capacity | l | 150 | |||
| Cooling Waer Consumption | l/hr | 800~1000 | |||
| Pump Motor Power | kW/HP | 7.5/10HP | |||
| BerrelHeating Power | kW | 4.5 | |||
| Total Weight | kW | 12 | |||
| OTHER | Machine Weight | tons | 2.2 | ||
| Machine Dimensions(LxWxH) | m | 2.2 x 1.2 x 2.6 | |||
| Shipping weight | tons | 2.4 | |||
| Shipping Measurements(LxWxH) | m |
2.0* 1.3*2.5 |
|||
Q1:Are you a trading company or a manufactory?
A1:We are a manufactory,can give u best service and low price.
Q2:What's your guarantee or the warranty of the quality if we buy your machines?
A2:We offer you high quality machines with 1 year warranty .
Q3:When can I get my machine after I paid?
A3:We will deliver the machines on time as the date we agreed both side.
