Product details

Manufacturer of PP/polyster pleated swimming pool spa filter element/ high flow particulate water filter cartridge

Introduction of 3M Parker replacement high flow PP Pleated water filter cartridge:
ZHIKE High flow rate filter cartridge, made with large diameter of 6 "or 6.5" and pleated form. It has the large filtering area and the pollutant capacity, can meet different kinds of flow requirements. With design of large diameter, in addition to increasing the effective filtring area, it can greatly reduce the use number of cartridge and reduce the size of filter housing. Therefore, in many applications, it has the advantages of large flow, long life filtering, frequency of cartridge replacement reducing and more convenient replacement. As rusult, it can greatly reduce the expenditure and manpower cost.

Applications of 3M Parker replacement high flow PP Pleated water filter cartridge:
1. Electronic industry: RO reverse osmosis water system prefiltration, deionized water system prefiltration.
2. Food industry: filtration of beverage, beer and mineral water.
3. Chemical industry: filtration of organic solvent and ink.
4. Pharmaceutical industry: filtration of pharmaceuticals, biologicals, serum products, compressed air and gas.
5. Others: filtration of plating solution, process fluids, photoresist and magnetic media
Filter 154422

The quality inspection standards for hydraulic filter elements of wind power gearboxes are based on:

1: ISO2942 filter element structural integrity determination

2: The filtration performance of ISO16889 filter element has been tested many times

3: ISO3968 filter pressure drop flow characteristic measurement

4: Determination of the anti-rupture properties of ISO2941 filter elements

5: Determination of anti-flow fatigue characteristics of ISO3724 filter element

6: ISO2943 material and liquid compatibility determination

7: Determination of rated axial load characteristics of ISO3723 filter element

Application:

The filter has been widely used in transformer oil, turbine oil, hydraulic oil, aviation kerosene, petroleum, chemical,
power plant, coal carbon, mining, pharmaceutical, food, and engineering industries.
Water Filter for Water Purify System

Technical parameters of filter element:

Number	Name	Unit	Parameter
1	Filtration accuracy	μm	1-100(Universal product filter element 10μm, can also be manufactured according to customer requirements)
2	Filter ratio β value	βx(c)	≥1000
3	Working pressure difference	bar	0-4
4	Filter element ultimate pressure difference	bar	≤4
5	Applicable medium		Petroleum base oil, water-glycol, water-oil emulsified oil, synthetic hydraulic oil
6	Filter material		Inert gradual diameter arrangement glass fiber filter material, filament fiber non-woven fabric, stainless steel woven mesh
7	Support material		Surface anti-corrosion protection treatment of high quality carbon structural steel
8	Seal ring material		Nitrile rubber or fluorine rubber
9	Filter element height	mm	82
10	Filter element diameter	mm	45
11	Expanded area of filter layer	sq	0.052s
12	Pollution holding capacity	g	14
13	Medium flow direction		Outside → inside
14	Bonding material		Epoxy adhesive
15	Temperature range		Nitrile rubber seal-43ºC~+107ºCViton seal-29ºC~+120ºC

Water Filter for Water Purify System
PRODUCT FEATURES:

1: It can filter solid pollutants with fast speed and high efficiency (βx(c) ≥1000) to better protect various control valves in the system.

2: The filter material is made of patented glass fiber and resin through a unique process. Has a fixed void structure. The fiber does not fall off. The intercepted object will not "penetrate" the filter layer due to the "pulsation" of the pressure difference and flow.

3: The filter material adopts gradually shrinking pore size structure from outside to inside along the direction of liquid flow to intercept pollutant particles of different sizes in layers to achieve deep dirt retention and greatly increase the service life.

4: Professional pleated technology production maximizes the filtration area, increases the flow processing capacity, and creates a uniform flow distribution.

5: Anti-impact fatigue filter material to improve the stability of fluid cleanliness. Improve filtration performance under harsh conditions on site.

6: Antistatic structure minimizes the generation and discharge of static charge and prevents static electricity from destroying filter elements and filter media.

7: The long service life saves costs and reduces the number of waste filter elements to be processed, which is energy-saving and environmentally friendly.

8: This product is a disposable filter element
Water Filter for Water Purify System

FAQ:

1. Are you a factory?
A: Yes, we are factory since 2010 and We have10years experience in foreign trade.

2. Which countries do you export to?
A: We are exporting to more than 50 countries, for example America, Australia, Germany, Brazil, Russia, Turkey, Dubai, India etc.

3. Could you do our brand?
A: Yes, just need your authorization.

4. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.

5. If your products bring us complaints, how will you deal with it?
A: If large quality, we will arrange shipment return and pay your lose.
B: If it big loses, like engine broken, we will pay all your cost which it brings you by cash or products.

6. What are you after sale service?
A: Offer product training, usually tells the difference in our products.
B: Offer technical support to help sales.
C: Refer to NO.4

7. How do you guarantee the quality of the product?
A: Our factory has established a comprehensive testing mechanism, and every step of the production has undergone a strict quality inspection.
