UPH type can be used for piston and piston rod seals. This type of seal has a large cross-section and can be used for a wide range of operations. The nitrile rubber and fluororubber materials used can ensure a wide range of operating temperature. range of use.
NBR O Rings UPH Application:
Working pressure: ≤32MPa, in order to prevent extrusion, when the pressure is higher than 15MPa, it is recommended to use a retaining ring at the root, which can ensure a large gap during normal operation.
Working temperature:
standard type (NBR) -30℃～+100℃
Heat-resistant type (FPM) -10℃～+150℃
Reciprocating speed: ≤0.5m/s
Medium:
(NBR) general petroleum-based hydraulic oil, water glycol hydraulic oil, oil-water emulsified hydraulic oil; (FPM) general-purpose petroleum-based hydraulic oil, phosphate ester hydraulic oil.
UPH Gasket Ring Installation:
Such O Ring Seals shall have an axial clearance (see columns h and H in the table). To avoid damage to the sealing lip, precautions should be taken during installation to avoid sharp edges.
Material:
The standard material is nitrile rubber, Shore Hardness (SHA) 90°.
Order example:
UPH-100A
or UPH-100*125*15
When ordering non-standard products, please specify when ordering
indicate. Such as: heat-resistant UPH-100A
