custom alumina ceramic switch faucet valve disc plate
The custom alumina ceramic switch faucet valve disc plate is a specialized component made from advanced ceramics. It is designed to be used in faucet valves to control the flow of water. The disc plate is made from alumina ceramic, which is a high-performance material known for its excellent mechanical and thermal properties.
The use of advanced ceramics in this switch faucet valve disc plate ensures durability, resistance to wear and corrosion, and high performance in demanding conditions. The ceramic material provides a smooth and precise operation of the switch, allowing for easy and accurate control of water flow.
Additionally, the disc plate serves as a ceramic insulator, preventing electrical conductivity and ensuring safety in the switch faucet valve. This ceramic insulator property is crucial in preventing any electrical short circuits and ensuring the reliable functioning of the faucet valve.
Item
Unit
Al2O3 95％－97％
Al2O3 99％
Desity
g/cm3
3.7
3.85
Flexural Strength
Mpa
300
340
Compressive Strength
Mpa
3400
3600
Modulus of Elaslicity
Gpa
350
380
Impact Resistance
Mpa m1/2
4.0
5
Weibull Moudulus
m
10.0
10
Vickers Hardness
HV0.5
1200.0
1300
Thermal Expansion Coefficent
10-6K-1
5.0-8.3
5.4-8.3
Thermal Conductivity
W/mK
24
27
Thermal Shork Resistance
△T℃
250
270
Maximum Use Temperature
℃
1600
1650
Volume Resistivity at 20℃
Ω
≥1014
≥1014
Dielectric Constant
KV/mm
20
25
Open Porosity
%
0
0
Dielectric Constant
ξr
10
10
Dielectric Loss Angle
Tanσ
0.001
0.001
If you are interested in the product, contact 2bvideo.com for more information for more information
