Manufacturer of Cementing Head
1) Application
The Cement Head is a special tool for pumping slurry and releasing plug. It makes the drilling fluid fill into casing in turn and quickly.
2) Features
a. Quick-latch adapter is designed to offer easier, faster and safer makeup for cementing casing.
b. Able to couple with two plugs simultaneously. Simplify the cementing operation and prevent cement pollution.
c. Positive lever indicates plug releasing.
d. Balance pipe is developed.
3) Technical Parameters
|
Specifications, mm |
Φ139.7 |
Φ177.8 |
Φ193.7 |
Φ244.5 |
Φ273 |
Φ339.7 |
|
Overall-length,mm |
1950 |
2020 |
2020 |
2360 |
2360 |
2440 |
|
Manifold |
2'' Union |
|||||
|
I.D. of plug container, mm |
Φ125 |
Φ160 |
Φ175 |
Φ225 |
Φ250 |
Φ320 |
|
Length of plug container, mm |
400 |
450 |
450 |
550 |
550 |
600 |
|
Working Pressure, Mpa |
35.5 |
35.5 |
35.5 |
35.5 |
35 |
35 |
4) Company Information:
Puyang Zhongshi Group Co., Ltd is a professional manufacturer of various oilfield equipments and cementing accessories since 1997, restructured enterprise of SINOPEC. Our group have 10 years export experience and 9 subsidiary factories, more than 500 employees. We are the first-class supplier of resources market of SINOPEC and CNPC.
We have the certificates of API 5CT, API 10D, API 11E, API 6A, API 11AX, ISO 9001 and ISO 14001. Our foreign customers are mainly from America, Central Asia, Russia, Southeast Asia, Middle East, etc.
Our products mainly include:
1. Pumping Unit 2. Tubing Pump/Sucker Rod Pump and Accessories
3. Float Collar & Float Shoe 4. Casing Centralizer
5. Cementing Plug 6. Cementing Head
7. Stage Collar 8. Casing/Tubing and Coupling
9. Drill Pipe 10. Sucker Rod
11. Air Blaster 12. Sucker Rod Guide
