It has the advantages of high degree of automation, easy use, high precision, high reliability, low price, and very simple operation and maintenance. It is widely used in the cosmetics industry, alcohol industry, home decoration industry, food industry, etc.
|
Power requirements (one) |
440V 3 P 60Hz 5KVA |
|
Compressed air pressure |
6-7Bar 100L/Min |
|
Gas Pressure |
0.8-2Bar |
|
Main motor power |
0.75KVA |
|
Gearbox ratio |
1：20 |
|
LED lamp power |
1KVA |
|
Machine size (L x W x H) |
1600mm×1200mm×1800mm |
|
Approximate weight (including conveyor) |
1100kg |
The machine can be installed as customer needs, equipped with a variety of automatic feeding system, such as vibration plate and rotary feeder etc.
This machine can be installed the surface treatment system separately according to the needs of customers, which can effectively solve the surface treatment of various plastic products, easy to operate, and meet different needs. Before printing plastic products, surface treatment is generally required to destroy the molecular structure of the surface and enhance the adhesion of the printed pattern; there are two surface treatment processes, one is flame treatment and the other is corona treatment.
If the machine finds no product on the transfer, the printing system won’t work when the jig comes to the printing position.
According to the different products, you can adjust the printing head stroke and the initial action angle of printing, so as to achieve the best printing effect.
Customers can choose different curing systems according to their own needs.
UV curing with mature technology, low lamp replacement cost and low maintenance cost.
Compared with traditional high-pressure mercury, LED curing has the characteristics of soft light output, long life, energy saving, safety and environmental protection, wide irradiation area, small space occupied, and uniform light spot, but it has the disadvantage of high maintenance and replacement cost.
