Product details

Chinese SEM630B 3ton wheel loader with CE approve

Product features

Advantages:


SEM wheel  loaders are a company under the machinery giant Caterpillar. The whole vehicle uses Carter's advanced technology,'whether it is engine or gearbox',which ranks among the top in China. The gearbox of Yamagong loader is a rare fixed-shaft type continuously variable transmission, which is comparable to Komatsu of Japan. In terms of hydraulic oil circuit, "Using Carter's advanced technology", both maneuverability and workability are better. In terms of engine, there are all with famous brand engine and engine spare parts .



3tons Wheel Loader 5 Jpg

3tons Wheel Loader 3 Jpg


Specification:

Specification:

Main Specifications

Rated load capacity Kg

3000

Operating weight Kg

9700

Bucket capacities M3

1.5-2.5

Overall Dimensions L*W*H (mm)

6890×2354×3080

Engine

Rated Gross Power

92kW/123hp

Model

Deutz WP6G125

Bore  mm

105

Stroke  mm

130

Displacement   L

6.56

Peak Torque  N.m

590

Operating Specifications

Max. Rimpull  kN

97

Breakout Force  kN

120

Full turn static tipping load  kg

5452

Hydraulic system

Pump displacement-implement pump  ml/rev

100

System Pressure setting Mpa

16.5

Hydraulic cycle times

Raise  s

4.7

Dump  s

1.0

Lower(Empty, Float Down) s

2.8

Total  s

8.5

Steering

Steering angle left/right  °

36°±1°

Minimum turning radius over rear tire  mm

4825

Minimum turning radius over bucket  mm

5946

Axle

Front

Fixed with calipers

Rear

Fixed with osc.frame and calipers

Maximum single-wheel rise and fall  °

±12°

Brake system

Service brake

Dry&caliper,Air-to-oil control

Parking brake

Drum-type shoe brake,spring applied & air released

Transmission

Type

Counter shaft  /  Power shift

Travel speed

I            /   II

Forward

7.4 km/hr   /  13.5km/hr

Reverse

9.2km/hr   /   31.1km/hr

Travel speed

III       /  IV

Forward

25.4km/hr  /  41.5km/hr

Service refill capacities

Cooling system  L

30

Engine lubricating oil  L

16

Oil for Converter and Gear box  L

45

Differentials and final drives



Front  L

10

Rear   L

10

Hydraulic tank  L

90

Tires

Size

17.5-25

Type

Bias

Layers

12

Textured type

L3 /E3

Air pressure

Front 350 KPa/Rear 300 KPa






Package :Nude or Polish with wax before shipping.



Certification:

OCEAN CERTIFICATE


It will be work smoothly toghter with our motor graders ,road rollers, crawler bulldozers etc.

we will treat our all customers like family! Welcome your new inquiry!
