LT301 F

SUPER ABRASION RESISTANT PETROLEUM DRILLING HOSE

Application：Flexible line using for delivery water-based, oil-based, acid-based and foam fracturing fluids underhigh pressure in acid,sand and hydraulicfracturing works.

Inner Tube：UPE and sythentic rubber

Reinforcement：multi-spiraled high tensile super flexible steel wire

Outer Laver: abrasion and weather resistant synthetic rubber：

Temperature Range:-29°C~+100°C(-20°F~+212°)：

Connector: integral union ,integralflange, or other connector types：
The SUPER ABRASION RESISTANT PETROLEUM DRILLING HOSE is a high-quality hose designed specifically for use in petroleum drilling applications. This api oil drilling hose is constructed with durable materials that provide exceptional resistance to abrasion, making it ideal for use in demanding drilling environments. With its superior abrasion resistance, this petroleum drilling hose offers reliable performance and long-lasting durability, ensuring efficient operation and safety during drilling operations. Trust the api 17k PETROLEUM DRILLING HOSE to meet the rigorous requirements of the petroleum drilling industry.

Size	I.D.	O.D.	W.P.	P.P.	Min.B.R.		W.T		Volume		Connector W.T		Connections
inch	mm	mm	psi	psi	m	ft	kg/m	lb/ft	bbl/min	m³/min	kg	lb/set	Connections
2"	32	81	15000	22500	1.2	3.94	11.5	7.7	4.5	0.72	30	66	2 "FIG1502 hammer connected by Wang or 2 1/16" 15KAPI flange 2 "FIG 1502 Hammer Union or 2 1/1615K APIfange
	44	95	15000	22500	1.4	4.59	18	12	9	1.46	53	117	3 "FIG1502 hammer connected by or 3 1/16" 15KAPI flange 3 "FIG 1502 Hammer Union or 3 1/1615KAPIflange
	51	107	15000	22500	1.4	4.59	20	13	12	1.91	55	121
2.5"	58	122	15000	22500	1.5	4.92	24	16	15	2.39	57	126
2.5"	64	126	15000	22500	1.5	4.92	27	18	18.5	2.90	58	128
3"	69	135	15000	22500	1.6	5.25	30	20	21.5	3.42	60	132
3"	76	145	15000	22500	1.6	5.25	35	24	26	4.13	65	143
4"	89	164	15000	22500	2.0	6.56	52	35	36	5.72	75	165	4 "FIG1502 hammer connected by Wang or 4 1/16" 15KAPI flange 4 "FIG 1502 Hammer Union or 4 1/16" 15KAPIfang
4"	102	179	15000	22500	2.0	6.56	60	40	47	7.47	85	187
5"	120	208	15000	22500	2.1	6.89	80	54	65	10.34	343	756	5 1/8 "15KAPI flange connection 5 1/815KAPIfange
5"	127	216	15000	22500	2.1	6.89	86	58	73	11.61	348	767	5 1/8 "15KAPI flange connection 5 1/815KAPIfange
5.5"	140	243	15000	22500	2.2	7.22	110	74	88.5	14.07	560	1235	7 1/16 "15KAPI flange connection 7 1/16 * 15KAPIfange
6"	152	255	15000	22500	2.3	7.54	125	84	104.5	16.62	680	1499	7 1/16 "15KAPI flange connection 7 1/16 * 15KAPIfange
2"	51	112	20000	30000	1.5	4.92	26	17	12	1.91	65	143	2 "FIG2002 Hammer Hammer Connection by Wang or 3 1/16" 20KAPI Flange 2 "FIG 2002 Hammer Union or 3 1/16" 20KAPIfang
2.5"	64	133	20000	30000	1.6	5.25	36	24	18.5	2.90	78	172	3 "FIG2002 hammering due to or 3 1/16" 20KAPI flange connection 3 "EIG2002HammerUnion or 3 1/1620KAPIflange
3"	76	159	20000	30000	1.9	6.23	57	38	26	4.13	98	216	3 "FIG2002 Hammer Union or 3 1/16" 20KAPI Flange Connection 3 "FIG 2002 Hammer Union or 3 1/16" 20KAPIflange
4"	102	202	20000	30000	2.1	6.89	94	63	47	7.47	400	882	4 1/16 "20KAPI flange connection 4 1/1620KAPIfange
5"	127	230	20000	30000	2.3	7.54	111	75	73	11.61	850	1874	7 1/16 "20KAPI flange connection 7 1/1620KAPIfange

Note: The actual parameters are subject to the final atlas
