Product details

LT795

Ultra High Pressure Thermoplastic NylonPolyurethane Hose

Scope of application ：suitable for conveying media such as water and hydraulic oil under high pressure, widely used in high-pressure cleaning and other industries

Pressure range： 690bar(10000psi)

Inner rubber layer： Nylon

Reinforcement layer： four layers of steel wire winding

Outer layer：black or colored polyurethane
The Ultra High Pressure Thermoplastic NylonPolyurethane Hose is an advanced, High Pressure Heated Hoses designed for use in demanding industrial applications requiring exceptional durability and reliability. This thermoplastic and fluoropolymer hose is engineered with a thermoplastic nylonpolyurethane blend, providing a robust construction that ensures superior resistance to abrasion, chemicals, and temperature extremes.

Key features include:

1. **High Pressure Resistance**: Capable of handling pressures up to 3000 psi (pounds per square inch), this hose is ideal for high-pressure fluid transfer systems in manufacturing, oil and gas extraction, hydraulic machinery, and other industries where pressure tolerance is critical.

2. **Thermoplastic NylonPolyurethane Blend**: The innovative material combines the strength and flexibility of nylon with the resilience of polyurethane. This results in a hose that maintains its integrity under extreme conditions while offering excellent bend radius and kink resistance.

3. **Durability and Longevity**: Designed for long-term use, this hose is built to withstand harsh environments without degradation. It can handle abrasive materials and corrosive substances without losing performance or integrity.

4. **Versatility**: Suitable for a wide range of applications, from fluid transfer to pneumatic and hydraulic systems, this hose offers a flexible solution for various industries including automotive, aerospace, marine, and construction.

5. **Ease of Installation and Maintenance**: Its lightweight design and standard compatibility with existing fittings make it easy to install and integrate into existing systems. Regular maintenance is minimal, ensuring operational efficiency.

6. **Safety and Compliance**: The hose is manufactured to meet stringent safety standards, ensuring operator safety and compliance with industry regulations.

In summary, the UHP thermoplastic hoses is a premium choice for applications that demand reliability, durability, and performance under challenging conditions. Its combination of high-pressure capability, material strength, and versatility makes it a preferred solution in a variety of industrial sectors.

Hose inner diameter I.D.			Outer diameter of hose O.D.	Working pressure W.P.		Burst pressure W.P.		Minimum bending radius MIN.B.P.	Reference weight W.T.
Dash	In.	mm	mm	MPa	psi	MPa	psi	mm	g/m
-4	1/4	6.3	12.5	69	10000	207	30000	110	255
-5	5/16	7.9	14.5	69	10000	207	30000	130	310
-6	3/8	9.5	17.2	69	10000	207	30000	150	375
-8	1/2	12.7	20.8	69	10000	207	30000	200	570

Note: The actual parameters are subject to the final atlas
