Guteli T-700

5 month ago

24 0

Dongguan Sante CNC Technology Co., Ltd

 6 month year

Product details

General Layout of the Machine; The T700-BT40 vertical drilling and tapping center utilizes a vertical frame layout with the vertical columns fixed to the bed.

The T700-BT40 vertical drilling and tapping center utilizes a vertical frame layout, where the columns are fixed to the bed and the spindle box moves up and down (Z direction) along the columns, the slide moves longitudinally (Y direction) along the bed and the table moves transversally (X direction) along the slide.Cnc Machining Center

The structure of the bed, table and workbench moves up and down (Z direction) along the studs, the slide moves longitudinally (Y direction) along the bed and the workbench moves transversely (X direction) along the slide.

The main parts of the bed, table, slide, columns and spindle housing are made of high-strength cast iron, molded in resin sand, twice aged.

The large parts of the bed, slide, column and spindle housing are made of high-strength cast iron, molded in resin sand, and twice aged to eliminate the effects of physical force. The optimized design of these large parts was carried out using Pro/E and Ansys to improve the design of the machine.

The optimized design of these large parts using Pro/E and Ansys improves the rigidity and stability of the large parts and the machine as a whole, and effectively suppresses the deformation and vibration of the machine caused by cutting force.

Second Hand Equipment,High Speed Machining Center,
