Metal Powder Filter Cartridge

The metal powder filter cartridge uses a deep fine polypropylene or fiberglass membrane as the filter material, with a large diameter of 6 inches/152mm, no center rod, one-way opening, and is designed for liquid flow from the inside out, ensuring that all contaminant particles are captured in inside the filter cartridge. The ultra-large flow design greatly reduces the use of filter elements and filters in applications with the same flow rate, greatly saving equipment investment costs and labor costs.

Filter media: Separates solid particles and impurities from liquids and gases

Related Liquid Filtration equipment,Automatic Filter,Scraper Self-cleaning Filter,Bag Filter,Basket Filter, Multi Media Filter,Quartz Sand Filter,Shallow Sand Filter,Caldle Filter,Ultra Precision Filter,Cartridge Filter and  PE/PA Sintered Filter Element,etc


Working principles of Metal Powder Filter Cartridge
Filtration status: Micron-level precision filtration can be achieved to separate solid particles and impurities in liquids and gases. When the fluid passes through the filter cartridge with a certain accuracy, the impurities are blocked on the surface of the filter cartridge to form a filter cake, and the pure fluid flows out through the filter cartridge, ensuring that the contaminated or impure fluid is purified into the state required for normal production, and ensuring that downstream equipment obtains Pure products or ensuring the normal operation of equipment. When the filter cake reaches a certain thickness, due to its high strength, the filter cartridge can be cleaned and reused by backwashing or backflushing with a certain back pressure.

Features of Metal Powder Filter Cartridge

 1. The sintered filter element is a new type of filter material made by vacuum sintering with high mechanical strength and overall rigidity.

 2. The mesh holes of each layer of the sintered filter element produced by the filter are interlaced with each other to form a uniform and ideal filtration structure.

 3. It has excellent filtration precision, filtration impedance, mechanical strength, wear resistance, heat resistance and processing performance.

 4. The comprehensive performance of this new type of sintered filter material is significantly better than other types of filter materials.

Advantage of Metal Powder Filter Cartridge

 1. Wide range of precision: It can be designed according to user needs, and the filtration precision is 1~300μm. The filtration area is large (5 to 10 times that of ordinary cylindrical filter elements).

 2. Long service life: It has great operational flexibility, easy process adjustment, and the material is not easy to leak. It can eliminate breakdown, short circuit, blockage and other faults, and has a long service life.

 3. Excellent material: The material is 304/316/316L/304L. Good corrosion resistance and heat resistance, suitable for high temperature and acidic environments.

 4. Customizable sizes: In addition to standard sizes (standard diameters are 25, 32, 40, 50mm, etc.), they can also be customized according to user requirements.

 5. High filtration precision, high mechanical strength, good wear resistance and good heat resistance.

Application of Metal Powder Filter Cartridge

Used for filtration of polyester, water treatment, oil products, medicine, food and beverage, chemical industry, chemical fiber products, and filtration of high-temperature air and other media.
