| Range | Band width | Band Thickness | Screw | N.M | ||
| inch | φ(mm) | mm | W1 W2 | W4 W6 | MXL | |
| 0.67"-0.75" | 17-19 | 18 | 0.6 | 0.4 | M5x40 | 5 |
| 0.79"-0.87" | 20-22 | 18 | 0.6 | 0.4 | M5x40 | 5 |
| 0.91"-0.98" | 23-25 | 18 | 0.6 | 0.6 | M5x40 | 5 |
| 1.02"-1.1" | 26-28 | 18 | 0.6 | 0.6 | M5x40 | 5 |
| 1.14"-1.22" | 29-31 | 20 | 0.8 | 0.6 | M6x50 | 15 |
| 1.26"-1.38" | 32-35 | 20 | 0.8 | 0.6 | M6x50 | 15 |
| 1.42"-1.54" | 36-39 | 20 | 0.8 | 0.6 | M6x50 | 15 |
| 1.57"-1.69" | 40-43 | 20 | 0.8 | 0.6 | M6x50 | 15 |
| 1.73"-1.85" | 44-47 | 22 | 1.2 | 0.8 | M6x60 | 15 |
| 1.98"-2" | 48-51 | 22 | 1.2 | 0.8 | M6x60 | 15 |
| 2.05"-2.17" | 52-55 | 22 | 1.2 | 0.8 | M6x60 | 15 |
| 2.2"-2.32" | 56-59 | 22 | 1.2 | 0.8 | M6x60 | 15 |
| 2.36"-2.48" | 60-63 | 22 | 1.2 | 0.8 | M6x60 | 15 |
| 2.52"-2.64" | 64-67 | 22 | 1.2 | 0.8 | M8x70 | 25 |
| 2.68"-2.87" | 68-73 | 24 | 1.5 | 0.8 | M8x70 | 25 |
| 2.91"-3.11" | 74-79 | 24 | 1.5 | 0.8 | M8X70 | 25 |
| 3.15"-3.35" | 80-85 | 24 | 1.5 | 0.8 | M8x75 | 25 |
| 3.39"-3.58" | 86-91 | 24 | 1.5 | 0.8 | M8x75 | 25 |
| 3.62"-3.82" | 92-97 | 24 | 1.5 | 0.8 | M8x75 | 25 |
| 3.86"-4.06" | 98-103 | 24 | 1.5 | 0.8 | M8x80 | 25 |
| 4.09"-4.41" | 104-112 | 24 | 1.5 | 0.8 | M8x80 | 25 |
| 4.45"-4.76" | 113-121 | 24 | 1.5 | 0.8 | M8x80 | 25 |
| 4.8"-5.12" | 122-130 | 24 | 1.5 | 0.8 | M8x80 | 25 |
| 5.16"-5.47" | 131-139 | 26 | 1.7 | 1.0 | M10x105 | 40 |
| 5.51"-5.83"" | 140-148 | 26 | 1.7 | 1.0 | M10x105 | 40 |
| 5.87"-6.34" | 149-161 | 26 | 1.7 | 1.0 | M10x105 | 40 |
| 6.38"-6.85" | 162-174 | 26 | 1.7 | 1.0 | M10x105 | 40 |
| 6.89"-7.36" | 175-184 | 26 | 1.7 | 1.0 | M10x120 | 40 |
| 7.4"-7.87" | 188-200 | 26 | 1.7 | 1.0 | M10x120 | 40 |
| 7.91"-8.39" | 201-213 | 26 | 1.7 | 1.0 | M10x120 | 40 |
| 8.43"-8.9" | 214-226 | 26 | 1.7 | 1.0 | M10x120 | 40 |
| 8.94"-9.41" | 227-239 | 26 | 1.7 | 1.0 | M10x120 | 40 |
| 9.45"-9.92" | 240-252 | 26 | 1.7 | 1.0 | M10x120 | 40 |
Features:
1) a very strong heavy duty band clamp with high levels of band tensile force
2) Bridge welded onto clamp band for optimal hose protection
3) Solid metal rollers complement the strength of the bands
4) Socket head screws allow for easy installation
5) Welded construction and raised edges increase the security and reliability.
Advantages:
1. The outer edge of the band with smoothing and shaping treatment precludes the damage of the hose.
2. using high quality material and precise stamping molding, prevents thread stripping.
3. with precise design, uniform stress, good sealing ability, can be twisted smoothly, and used multiple times.
